Epson EH-TW5700 Full HD Home Theatre Smart Projector

Epson EH-TW5700
Delivery

DISCONTINUED

For current models Click Here:
Epson

2yr warranty
australian stock
insured delivery
1080P resolution

Specifications

  • 1080p 1920 x 1080 16:9
  • 2700 ANSI Lumens
  • 35,000:1 Contrast
  • 3.6kg Weight
  • 28db Fan Noise (eco)
  • 2 Year Warranty
  • 1 Year/750Hr lamp Warranty
  • Est. Lamp Life up to 7,500hrs

Key Features

  • Chromecast Inbuilt
  • Android TV Streaming
  • Horizontal & Vertical Keystone
  • Frame Interpolation
  • 10W Speaker Inbuilt
  • Bluetooth Audio

Epson EH-TW5700 Throw Distance Chart

Throw Ratio: 1.22-1.47:1
Examples of installation distance for some popular screen sizes.
Image Size Installation Distance
92" (16:9) 2030x1140mm From 2.5m to 2.9m
100" (16:9) 2130x1200mm From 2.6m to 3.1m
110" (16:9) 2435x1370mm From 3.0m to 3.5m
120" (16:9) 2657x1494mm From 3.3m to 3.9m
135" (16:9) 2990x1681mm From 3.7m to 4.3m
150" (16:9) 3320x1867mm From 4.1m to 4.8m

Epson EH-TW5700 Projector

The new Epson EH-TW5700 is part of a new generation of Smart projectors featuring an inbuilt Chromecast for easy viewing of your favourite entertainment apps from your Android or iOS smart phone, tablet, iPhone, and iPad. It also comes with the new SMP or Streaming Media Player for stand alone wireless streaming from over 4,000 apps without the need for an external smart device. The TW5700 features a convenient inbuilt speaker for stand alone entertainment and the ability to output audio by cable or Bluetooth for big cinema sound. The EH-TW5700 isn’t just clever it features both detail enhancement for a sharper more detailed image and frame interpolation increasing frame rate for a smoother image especially handy for fast motion. Amazingly it features an inexpensive replacement lamp ($119rrp) making it cheap to run long term.

KEY FEATURES and BENEFITS

  • 1080p High Definition – for Full HD movies, games and more - up to 330" on virtually any wall or screen.
  • Bright Images – 2,700 Lumens colour brightness and 2,700 Lumens white brightness for entertainment in any environment
  • Smart TV – a Smart Media Player (SMP) is included so you can watch your favourite content from apps with a simple-to-use remote that features voice search
  • 35,000:1 Contrast Ratio – contrast ratio up to 35,000:1 delivers a high range of colour and detail in both bright and dark scenes
  • New Viewing Functions – heighten your gaming experience with advanced features such as 21:9 ultra-wide full HD mode and dark gamma uplift
  • Detail Enhancement – enhance standard definition content to make your entertainment come alive
  • Frame Interpolation – for smoother, sharper and more realistic action scenes
  • Captivating Sound – enjoy a built-in 10W stereo speaker for life-like sound
  • Exciting 3D Adventures – delivers eye-popping 3D entertainment at home with RF 3D glasses (sold separately)
  • Low Cost of Ownership – Long-life, cost efficient lamps and a High Efficiency Filter extends the life of your projector and allows for hassle free maintenance
  • Easy to Use – A new simple welcome guide and easy-to-use remote puts all the most commonly used functions right at your fingertips
  • 2 Year Projector Warranty – Enjoy peace of mind.

warranty

Brighter, Vivid Projection

White brightness alone cannot bring the true colours you see everyday. While other manufacturers of 1-chip DLP technology believe they can improve image quality by just increasing the brightness of their projectors’ white light output, Epson ensures that its projectors combine brightness and True Colour to create vibrant and realistic images with 3LCD technology across every projector model.

3LCD Technology

All Epson projectors are based on 3-chip LCD technology for amazing colour, incredible detail and solid reliability. 3LCD’s 3-chip architecture dedicates an entire chip to process each primary colour – red, green and blue, continuously. Unlike single-chip technology that delivers colour sequentially, you get full-time colour. The result is vibrant, realistic images and video all delivered with 3LCD’s true-to-life colour.

Flexible Positioning

Project up to 330" on virtually any wall or screen and have the versatility of 1-1.2x optical zoom and auto vertical keystone correction for easy adjustments in a variety of spaces. Convenient horizontal keystone correction allows you to have the projector off centre to the left or right and still square up the image.

EH-TW5700 zoom and keystone

Detail Enhancement

With a state of the art upscaling called detail enhancement, the EH-TW5700 can improve the detail of many images. Even pictures that have been zoomed in or enlarged can be sharpened to look clearer through this upscaling process.

EH-TW5700 Detail enhancement

Frame Interpolation

Frame interpolation technology inserts multiple new frames between the original ones, so motion appears smoother, sharper and more realistic. Film is encoded on Blu-ray at 24 frames per second. FineFrame deconstructs and reconstructs these sources for a 1080p frame rate output of up to 120Hz, virtually eliminating flicker and frame-to-frame judder.

EH-TW5700 Frame interpolation
EH-TW5700 Frame interpolation

EH-TW5700 Chromecast

Chromecast built-in

Cast your favourite entertainment apps— movies, TV shows, music, games, sports and more — from your Android or iOS device, Mac or Windows computer for flexible viewing with simple set-up.

Streaming Media Player for Smart Entertainment

With a smart media player imbedded in the projector, you now have the option to select from over 4,000 content apps including already pre-installed apps. It’s now easier than ever to stream your favourite series, live sporting events, or simply watch the latest blockbuster movie with the EH-TW5700.

EH-TW5700 Streaming media player

Low Cost of Ownership

Traditionally projectors have features a short lamp life and an arm and a leg for a replacement. The new EH-TW5700 offers a lengthy 7,500 hour lamp life for endless home entertainment and an affordable lamp so you can enjoy your big screen entertainment for years to come. At only $119 the replacement lamp is one of the cheapest in the industry.

Captivating Sound

Setting up the EH-TW5700 is even easier with a built-in 10W speaker to provide life-like sound. Have more control over your experience with the additional option of aptX Bluetooth connectivity to external speakers to further amplify your entertainment.

Dark Gamma Uplift

Achieve a new level of gaming by using dark gamma uplift to brighten up dark areas and provide a broader view so you never miss what’s happening on the screen.

EH-TW5700 Gamma uplift

Specifications
PRODUCT NAME EH-TW5700
WHAT'S IN THE BOX
  EH-TW5700 Projector, Power Cable, Remote Control + Batteries,
TECHNOLOGY
Projection System 3LCD
LCD Panel 0.61-inch wide panel
Lamp Type 200W UHE
Colour Light Output 2,700 Lumens
White Light Output 2,700 Lumens
Pixel Number 2,073,600 dots
(1920 x 1080)
Native Aspect Ratio 16:9
Contrast Ratio 35,000:1
Colour Reproduction Up to 1.07 billion colours
Colour Processing 10 bit
Keystone Correction Vertical: -30 to +30 degrees
Horizontal: -30 to +30 degrees

Optical Zoom 1 - 1.2 (Optical)
Screen Size 34" to 332" [0.91 to 9.11 m] (Zoom: Wide)
34" to 332" [1.09 to 10.94 m] (Zoom: Tele)
Projection Distance example 80" screen 2.17 – 2.61m
Throw Ratio 1.22 (Zoom:Wide), 1.47 (Zoom:Tele)
Projection Lens F Number 1.49 - 1.72
Projection Lens Focal Length 16.9 - 20.28mm
Focus Method Manual

CONNECTIVITY
Input: Servicing 1 x USB mini B (service)
Input: Digital 1 x HDMI
Output: Audio 1 x 3.5mm Audio out (not compatible with volume adjustable headphones)
Speaker Output 1 x 10W
ADVANCED FEATURES
Smart Media Player (SMP) Yes
Wireless Yes (via SMP)
21:9 ultra-wide full HD Yes
Dark Gamma Uplift Yes
Detail Enhancement Yes
AV Mute Yes
Frame Interpolation Yes
3D Display Yes
Direct Power On Yes
Bluetooth Audio Yes (SBC, aptX)
Security Kensington®-style lock provision
Colour Modes 2D : Dynamic, Bright Cinema, Natural, Cinema

GENERAL
Dimensions D x W x H 308 x 309 x 107 mm
Weight Approx. 3.6kg
Projector Warranty 2 Years
Lamp Warranty 1 Year or 750 Hours*
Power Consumption: Lamp on 297 W
Power Consumption: Standby 0.3 W
Noise Level Normal / Eco: 36 / 28 dB

What's in the Box
EH-TW5700 remote control
Remote Control
power cord
Power Cord

Rear Panel

EH-TW5700 rear panel
