Display
Type
DLP
Resolution Type
SVGA
Resolution
800 x 600
Brightness (ANSI Lumens)
3,600
Throw Distance
3.9 - 43 ft / 1.19 - 13.11 m
Throw Ratio
1.96 ~ 2.15
Display Size (in.)
30 - 300 in. / 0.76 - 7.62 m
Keystone
Vertical (± 40º)
Lens
1.1x optical zoom
Light Source (watt)
190
Light Source Life, Normal (hours)
4500
Light Source Life, Dynamic Eco-Mode (hours)
15000
Color Depth
1.07B Color (R/G/B 10bit)
Dynamic Contrast Ratio
22,000:1
Aspect Ratio
4:3
Video Signal
Frequency Horizontal
15K~102KHz
Frequency Vertical
23~120Hz
Compatibility
PC Resolution (max)
VGA (640 x 480) to WUXGA_RB (1920 x 1200)
Mac® Resolution (max) VGA (640 x 480) to WUXGA_RB (1920 x 1200)
Connector
Mini USB Type B
1
Audio Output (Mini Jack)
1
3.5mm Audio In
1
Control (RS232)
1
HDMI 1.4
1
VGA In
2
VGA Out
1
Composite RCA Video In
1
Audio
Internal Speakers
2W
Power
Voltage
AC 100-240V (universal), 50-60Hz
Consumption (typical) 260W
Stand-by<0.5W
Operating Conditions
Temperature
32-104º F (0–40º C)
Gross (lbs)
7.14
Weight (metric)
Net (kg)
2.22
Gross (kg)
3.24
Dimensions (metric) (wxhxd)
Packaging (mm)
365 x 300 x 188
Physical (mm)
294 x 218 x 110
General
Regulations
FCC (including ICES-003), cTUVus
PACKAGE CONTENTS
PA503S projector, power cable, VGA cable, remote control, Quick Start Guide, ViewSonic Wizard CD (with User Guide)
|
