Quick Facts: |
|
Optoma UHD50X Throw Distance Chart (Examples for common Sizes) T/R: 1.21:1.59:1 |
Image Size |
Installation Distance
(Approx. To Lens) |
92" (16:9) 2030x1140mm |
From 2.5m to 3.2m |
100" (16:9) 2130x1200mm |
From 2.6m to 3.3m |
110" (16:9) 2435x1370mm |
From 3.0m to 3.8m |
120" (16:9) 2580x1450mm |
From 3.2m to 4.1m |
135" (16:9) 2990x1681mm |
From 3.7m to 4.7m |
150" (16:9) 3320x1867mm |
From 4.1m to 5.2m |
|
SPECIFICATIONS
Native Resolution: UHD 3840 x 2160 16:9
Brightness: 3400 ANSI Lumens
Maximum Contrast: 500,000:1
Weight: 3.9kg
Fan Noise: 26db (eco)
Warranty: 2 Years (+1 Year $135)
Lamp Warranty: 12months/1000hrs
Lamp Life Up To: 15,000hrs |
FEATURES
- HDR10 Compatible
- 1.3x Zoom
- 10% Vertical Lens Shift
- Vertical Keystone Correction
- HDMI Connection
- HDMI 2.0 Connection
- 10W Speaker
- 12 Volt Trigger
- 3D Capable(3D glasses required)
- Fast Gaming Modes
|
Optoma UHD50X 4k Gaming Projector
The UHD50X has been designed to bridge the gap between 4K theatre movie projectors and high speed gaming projectors with inbuilt gaming modes that provide an incredible 15.7ms response time. You can get all the incredible detail of 4K movies but then flick the UHD50X into gaming mode and dominate on the battle field.
With a new 8 segment colour wheel the UHD50X produces incredible REC.709 colour but still is able to pump out an brilliant 3400 lumens brightness for lit room entertainment. The UHD50X is compatible with the new HDR10 standard for a higher dynamic range in the image producing bright whites and deeper dark shading on screen at the same time. It projects deep black levels with its huge 500,000:1 contrast and produces a crisp clear 4K UHD image. (Also known as UHD30 in some markets)

Bring the cinematic 4K UHD experience home with the Optoma UHD50X
- The World’s First 240Hz Cinema Gaming Projector
- Superb Gaming Experience with low 15.7ms Input Lag in Enhanced Gaming Mode
- Bright Room Design with Brightness 3,400 lumens & 500,000:1 Contrast
- Immersive True 4K UHD Resolution with Perfect Pixel Alignment
- BrilliantColor & RGBWRGBW 8 Segment Color Wheel for the Truest and the Most Accurate Colors
- HDR 10 & HLG Supported for Brightest Whites, Deepest Darks, and Lifelike Colors
- Auto 3D Display with ISF Calibration Setting
- HDMI 2.0 Support for Connection to 4K Entertainment
Behold for the fastest projector on earth! Featuring the lightning-fast refresh rate and the low input lag, UHD50X is the world’s first 240Hz projector, perfectly quenching your desire for the ultimate home entertainment, no matter in movie watching or gaming. With true 4K UHD resolution, UHD50X will bring the immersive cinema and gaming experiences in 120″ screen. The different display options also allows optimized performance in cinema mode, gaming mode, or 3D mode, delivering images and motions with ultimate smoothness and clarity.
4K UHD Resolution
The UHD50X is a new breed of projector with an Ultra HD 4K resolution giving you four times the detail of a full HD projector. This delivers a sharper clearer picture perfect for the new generation of gaming consoles and 4K disks.
 |
HDR10 and HLG compatible
The Optoma UHD50X supports HDR10 and HLG. When a HDR/HLG signal is imported, the projector automatically switches to HDR / HLG display mode. Through Optoma’s HDR color mapping and tone mapping technology, it enables HDR / HLG movies or games to be presented with optimized performance in the accurate color and dynamic contrast.
|
True Colors Tell The Realistic Stories.
UHD50X incorporates RGBWRGBW 8 segment color wheel to achieve vivid and stunning color performance with 3,400 high lumens of brightness. Optoma’s specialized color calibration and adjusting technologies exceeds HDTV Rec. 709 standards to present the truest and the most accurate colors, for authentic, and in-depth storytelling images. This is a 4K HDR high resolution home theater that you will not want to miss out! |
 |
 |
Vertical lens shift
The UHD50X also offers a 10% vertical lens shift for a bit more flexibility on installation. This ensures you don't have to be completely exact with the installation height and allows for a little bit of margin for error.
Dynamic Black technology
This feature gives more contrast providing depth to your image by smoothly adjusting the lamp output. Based on the brightness information of each frame the UHD50X is able to dimm or brighten the lamp to create a stunning high contrast ratio. Bright scenes appear crisp and clear, while dark scenes remain detailed with deep inky blacks and exceptional light and shade detail.
Lag-Free Gaming
15.7ms Input Lag
For party games or PC gamers, UHD50X is the first choice in Optoma True 4K UHD projector. It incorporates “Enhanced Gaming” mode with super low input lag. Gamers enjoy low-latency between operation of controls and win the game in milliseconds.
Input source |
4K
60Hz |
1440p
60Hz |
1080P
60Hz |
1080P
120Hz |
1080P
240Hz |
Input lag |
25.8ms |
23.8ms |
23.8ms |
18.2ms |
15.7ms |
|
Note:
1.*Output format: Only for 1080P 240Hz signals.
2.The input lag by signals is described in the left table.
3.The values in the table can vary slightly.
Projecting on Any wall
Six color compensation are provided to suit different types of wall spaces in the home and avoid distortion of colors. Even in the absence of a projection screen, images can be viewed on a wall space with the most accurate color gamut.
Flexible Adjustment
26dB Quiet Fans
In Eco Mode, only the quiet-running fans emit 26dB. Movies can be viewed without interference from projector operating noise.
|
Specifications
UHD50X Specification
Display Technology |
DLP 4K UHD chip |
Native Resolution |
4K UHD (3840 × 2160) |
Brightness |
3400 ANSI Lumens |
Contrast |
500,000:1 |
Light Source |
Lamp |
Lamp Life |
4,000/10,000/15,000 hours (Bright/STD/DynamicBlack) |
Throw Ratio |
1.21 – 1.59:1, ±3% |
Zoom Type |
1.3x Manual |
Lens Shift |
105% – 115% ± 5% |
Keystone |
± 40° Vertical |
I/O Connectors |
HDMI 1.4a x1
HDMI 2.0/ HDCP2.2/ MHL 2.1 x1
VGA In x1
Audio In (stereo, 3.5mm jack) x1
USB-A (for 5V PWR 1.5A/ MStar firmware upgrade) x1
USB 2.0 (for firmware upgrade) x1
RS-232C male(9-pin D-SUB) x1
Audio Out 3.5mm x1
S/PDIF Out (2 Channel Stereo PCM) x1
12V Trigger(3.5mm jack) x1 |
Speaker (Watts) |
10W |
Weight (Kg) |
3.9 ±0.5kg |
Dimensions (W x D x H) (mm) |
315 x 270 x115 mm (w/o feet), 315 x 270 x118 mm (w/ feet) |
Aspect Ratio |
16:9 |
Projection Screen Size |
34.1" – 302.4" |
Projection Lens |
F#1.94~2.23, f 12.81~16.74mm |
Uniformity |
80% |
Horizontal Scan Rate |
31~135KHz |
Vertical Scan Rate |
24 – 120Hz (1080p/240Hz at Enhanced Gaming Mode) |
Displayable Colors |
1073.4 million colors (10 bit) |
3D Support |
Full 3D |
Noise Level |
26dB |
Power Supply |
100240V, 5060Hz, auto-switching |
Power Consumption |
<0.5W (standby), 336W (max) |
RoHS |
Compliant |
Supplied Accessories
|
Remote |
|
|
|
