BenQ TK800M DLP 4K Home Entertainment Projector

TK800M








Australian 2 Year Warranty


DISCONTINUED

For the current BenQ Range Click here

Quick Facts:
BenQ TK800M Throw Distance Chart (Examples for common Sizes) T/R 1.5-1.65:1
Image Size Installation Distance
(Approx. To Lens)
92" (16:9) 2030x1140mm From 3.1m to 3.3m
100" (16:9) 2130x1200mm From 3.2m to 3.5m
110" (16:9) 2435x1370mm From 3.7m to 4.0m
120" (16:9) 2657x1494mm From 4.0m to 4.3m
135" (16:9) 2990x1681mm From 4.5m to 4.9m
150" (16:9) 3320x1867mm From 5.0m to 5.4m
SPECIFICATIONS
Native Resolution: UHD 3840 x 2160 16:9
Brightness: 3000 ANSI Lumens
Maximum Contrast: 10,000:1
Weight: 4.2kg
Fan Noise: 33 / 29db (eco)
Warranty: 2 Years (+1 Year $135)
Lamp Warranty: 6months/750hrs
Lamp Life Up To: 15,000hrs
FEATURES
- Rec. 709 Colour Calibration
- Flawless All Glass Optics
- 1.1x Zoom
- Vertical Keystone Correction
- 2x HDMI connections
- HDR Compatible
- 3D Capable(3D glasses required)
- 12 Volt Trigger

BenQ TK800M 4K UHD Sports Home Projector

The BenQ TK800M is a new release 4K projector offering ultimate detail and has been designed from the ground up for use in a in a bright environment making it the perfect projector for watching sports. Motorsport, Cricket, football, soccer, even horse racing will look fantastic in Ultra HD 4K. With new foxtel and netflix 4K offerings it is really the the futureproof resolution. The powerful 3000 lumen brightness gives you flexibility so you don’t have to have a blacked out theatre room to use it.

BenQ TK800M Reviews :


Performance
Features
Ease Of Use
Value

"Input Lag: Input lag at 44 ms on the TK800M is slightly faster than the 50 ms on the W1700. This is fine for most casual gaming, but serious or professional gamers may want a faster unit since many 1080p projectors can get down to 16 ms. However, they are not 4K projectors - 44 ms is about as fast as we've seen on 4K models"

From a value perspective, the BenQ TK800M combines 4K resolution with a bright picture, very good uniformity, 3D capability (at 1080p), and a two year warranty for under $2499. Vivid TV mode in particular gives it extra vibrance for ambient light viewing. If that combination of features for that price hits your hot button, we believe you'll have a lot of fun with the TK800M. "



Home Entertainment Projector for Sports Fans with 4K HDR,3000lm | TK800M

  • True 4K HDR with XPR Technology
  • Vivid Colors and High Brightness for Living Room Ambient Light
  • Dedicated Modes for Football & Sports Enjoyment for Sports Fans
  • True 4K HDR for Immersive Live Sports
  • 96% Rec.709 Colour coverage

To fully enjoy the beautiful game at football parties in a bright living room or backyard BBQ, a huge 100"+ projected 4K UHD 8.3 million pixel picture with vivid HDR color in any lighting can't be beat. And custom Football & Sport modes with powerful sound put you in the action as if you’re in the stadium, all in a stylish, compact design with easy setup.

Superb Image Quality

4K UHD True 8.3 Million Pixel Perfection

Producing 4K UHD 3840x2160 resolution with 8.3 million distinct pixels for each frame with XPR technology, TK800M utilizes revolutionary 0.47” single-DMD DLP technology to minimize the sleek, compact profile for modern lifestyles. With four times the resolution of Full HD 1080p, 4K UHD reduces pixel blur for stunning clarity and crisply defined fine details.

TK800M Resolution

Image Integrity and Color Accuracy

With single DMD DLP technology to avoid inherent alignment issues of multiple panels, TK800M ensures immaculate image integrity and color accuracy. TK800M generates razor-sharp images and accurate colors devoid of artifacting such as blur, shadowing, and interference patterns for immaculate clarity.

TK800M 4K UHD

4K Lens System with Flawless Optics

TK800M’s 4K optical system uses only the highest grade glass for superior realistic image quality. Precision 7-element 4-group lens array allows greater light penetration for long-lasting 4K intensity, and low-dispersion lens coatings minimize chromatic aberration so you can enjoy your favorite 4K UHD content in brilliant clarity.

TK800M Lens

Vivid Colors in Living Room Ambient Light

Bringing total visual enjoyment for all your home entertainment, BenQ color expertise perfectly balances high visual brightness and vivid colors for well-lit environments, especially for exciting sport matches. So you can watch sports and movies, or play games with family with lights on to see the joy on their faces.

TK800M Resolution

New 4K Color Wheel for Vivid Colors

TK800M’s innovative new 4K color wheel delivers stunning color performance, achieving 92% of Rec. 709 color space. Reproducing vivid colors with nanometer-level precision pure color coatings and ultra 120Hz refresh rate to eliminate image blur, TK800M perfectly balances color accuracy and brightness with stringent quality control.

TK800M REC.709

Hyper-Realistic Projector-Optimized HDR

Supercharged by HDR10 content support with BenQ exclusive Auto HDR Color Rendition and projector-optimized technology, TK800M’s High Dynamic Range offers greater brightness and contrast range than SDR, with image optimization in a single step to bring out every detail in 4K content for ultimate home entertainment.

TK800M HDR

Dedicated to Showcase the Beautiful Game

Football Mode

Football Picture Mode preserves lifelike skin tones and lush green grass for stunning larger than life big-screen projection of every second of the match. And Football Sound Mode clarifies the announcer's every comment even as you're immersed in the cheering crowd in the open-air stadium atmosphere.

TK800M football Mode

Sport Mode

Sport Picture Mode renders realistic skin shades, warm wood tones, and vivid reds with balanced green and blue for stunning big-screen projection of fast-paced indoor sports action on wooden courts. And Sport Sound Mode accentuates the announcer's commentary and clear acoustic details of squeaking sneakers, referee whistles, and scraping skates in an indoor arena.

TK800M Sports Mode

CinemaMaster Audio+ 2 for Massive Sound

Upgraded with dramatically wider frequency range from powerful 5-watt audio housed in a resonant sound chamber for deep bass and soaring highs, BenQ CinemaMaster Audio+ 2 audio-enhancing technology also provides exclusive EQ algorithms for pure clarity and sensual sound quality as used by Hollywood studios.

TK800M Cinemaster audio

Delicate Details and Pure Vocals

TK800M’s aluminum driver diaphragm performs the pure vocals and delicate details in mid- and high frequencies.

Deeper Resonant Bass

The resonance chamber enhances the wider frequency range especially for deeply resonant bass from a compact speaker.

Long Lasting Sensual Sound

Heat-resistant NdFeB magnets ensure long lasting sensual sound quality without distortion.

Simple & Convenient Lifestyle Design

TK800M’s lightweight design and sleek, compact profile accentuates beautiful aesthetics as well as intuitive functionality and eco-friendly design. A chic addition to your living room décor with easy setup, TK800M makes your home entertainment simple and comfortable for friends and family to enjoy parties, sports, movies.

Long Lamp Life TK800M

Power Saving and Long Lamp Life

An ingenious solution that intensifies your viewing pleasure while saving money, BenQ SmartEco™ technology automatically adjusts lamp brightness based on content to project richer blacks and increase contrast for image details. Economic Mode further extends projector lamp life up to 10,000 hours, minimizing lamp replacements and maintenance for an overall lower cost of ownership.

TK800M keystone

Auto Keystone for Easy Setup

Countering the trapezoid effect when the projector must be placed off-center, such as simple placement on top of a table, the vertical keystone function adjusts the image for a professionally squared image. Keystone correction makes it simple to project ideally aligned images from a variety of locations.

1.2X Zoom for Big Picture Flexibility

1.2X zoom extends available space with a flexible range of throw distances for big-screen entertainment without the hassle of complicated installation.

*Place the BenQ projector at the right distance to maximize visual enjoyment, key in the number and let the “Throw Distance Calculator” do the math for you.






Specifications
Display
Projection System DLP
Resolution 4K UHD (3840 x 2160)
Resolution Support VGA (640 x 480) to 4K UHD (3840 x 2160)
Brightness (ANSI lumens) 3000 ANSI Lumens
Contrast Ratio (FOFO) 10,000:1
Display Color 30 Bits (1,07 billion colors)
Native Aspect Ratio Native 16:9 (6 aspect ratio selectable)
Light Source Lamp
Light Source Wattage 240W
Light Source Life

Normal 4,000 hours
SmartEco 8,000 hours
Economic 10,000 hours
LampSave 15,000 hours


Optical
Throw Ratio 1.50 - 1.65 (100" @ 3.32 m)
Zoom Ratio 1.1x
Keystone Adjustment 1D, Vertical ± 40 degrees
Projection Offset 110%
Clear Image Size (Diagonal) 60"~200" / 300"
Image Size 30" ~ 300"
Horizontal Frequency 15K - 102KHz
Vertical Scan Rate 23 - 120Hz

Color Wheel Segment 4-Segment (RGBW)
Rec.709 Coverage 96%

Audio
Speaker 5W x 1

Interface
PC (D-Sub) x 1 PC In-1 (D-sub 15pin, Female)
HDMI x1 HDMI-1 (HDCP2.2)
x1 HDMI-2 (HDCP1.4)
USB Type A x1 USB Type A(1.5A power)
USB Type mini B x1 USB Type mini B (Service)
Audio in (3.5mm Mini Jack) x 1 Audio In (mini jack)
Audio out (3.5mm Mini Jack) x1 Audio Out (mini jack)
RS232 (DB-9pin) x1 RS232 In (D-sub 9pin, male)
DC 12V Trigger (3.5mm Jack) x1
IR Receiver x2 (Front/Top)
Security Bar Security Bar, Kensington Lock

Special Feature
HDR Yes (HDR10, HLG)
CinemaMaster Audio+2 Yes

Compatibility
HDTV Compatibility 480i, 480p, 576i, 567p, 720p, 1080i, 1080p, 2160p

Environment
Power Supply VAC 100 ~ 240 (50/60Hz)
Typical Power Consumption Max 385W, Normal 330W, Eco 250W
Standby Power Consumption 0.5W Max. at 100 ~ 240VAC
Acoustic Noise (Typ./Eco.) 33/29 dBA
Operating Temperature 0~40℃

Dimension and Weight
Dimensions (W x H x D)(mm) 353 x 135 x 272 (mm)
Net Weight (Kg/ lbs) 4.2 kg / 9.2 lbs

Accessories (Standard)
Remote Control w/ Battery x 1 (RCV015) w/ AAA Battery x 2
Power Cord (by region) x 1 (3m)
User Manual CD Yes
Quick Start Guide Yes
Warranty Card (by region) Yes

OSD
OSD Language Arabic/ Bulgarian/ Croatian/ Czech/ Danish/ Dutch/ English/ Finnish/ French/ German/ Greek/ Hindi/ Hungarian/ Italian/ Indonesian/ Japanese/ Korean/ Norwegian/ Polish/ Portuguese/ Romanian/ Russian/ Simplified Chinese/ Spanish/ Swedish/ Turkish/ Thai/ Traditional Chinese (28 Languages)


Rear Panel
TK800M Rear



Optional Accessories

Projector Warranty Upgrades

Extended Warranty For Projectors
All Programs come with:
- GM Multimedia Extended Warranty ID Number (must be retained)
- GM Multimedia claim instructions and terms & conditions
- Does not cover consumable items or accessories such as projector globes or remotes
[More Information]
1 Year Warranty
2 Year Warranty
$135
$195

BenQ 3D 5J.J9H25.001 Wireless Glasses DGD5

Your Price:
$99.95

Normally $129.95

5J.J9H25.001

The BenQ DGD5 3D Glasses create an immersive 3D viewing experience with BenQ's DLP Link-enabled projectors. The glasses have an estimated 30 hour continuous run time between recharging. * may be worn over most prescription eyeglasses * compatible with all BenQ DLP-link 3D projectors.

Contrast Ratio 1200:1
Weight 32g
Detect Type DLP Link (Photo Sensor)
Batteries Rechargable Battery
Accessories Storage puch, Cleaning Cloth, USB Cable, User Guide

Universal Flush Projector Ceiling Mount FB-1 *Recommended*
White - $149
Black - $149

Projector Mount

SPECIFICATIONS
Available in BLACK (FB-1B) and WHITE (FB-1W)
• Swivel: 360°, Adjustable roll, pitch and yaw.
• Rigid Steel construction.
• Durable powder-coated finish (Black or White).
• Supports up to 10kgs.
• Mounting hardware included.
• User manual included.
• All bracket models come standard with 4 x mounting arms.

FEATURES
- Direct to ceiling mount (150mm)
- Suits most projectors with 3 or 4 holes


HDMI Logo

HDMI Cable

Premium HDMI Digital AV Cable - For 4K, 1080P & 3D Projectors

1 Metres
$19.95
2 Metres
$29.95
3 Metres
$39.95
5 Metres
$49.95
10 Metres
$79.95
15 Metres
$99.95
20 Metres
$149.95

  • High Speed HDMI CAT2 cable
  • Type A to Type A Male-to-Male High Speed cable with Ethernet Channel
  • Designed to support the features of HDMI V2.0 and previous versions
  • Features include 4K (50/60Hz) Video, 3D, Deep Colour, Audio Return Channel
  • High Speed HDMI performance with a dedicated Ethernet channel.
  • Shieled cable construction for optimum RF & EMI Protection
  • Gold Plated terminals
  • 12 Month Warranty
    *We recommend keeping the length short for 4K under 10m - especially for 60hz
