| BENQ W500 LCD High Definition Home Theatre Projector |
| |
 |
|
 |
|
 |
SenseyeT Contrast Enhancement
The W500 maintains high contrast, whatever's on screen and wherever you're watching.
An eye to great viewing
The W500 features an iris-like lens design that mimics our own eye, adjusting the aperture after analyzing the incoming video signal. The aperture is contracted during dark scenes for truer black tones and enhanced detail, while it is enlarged for bright scenes to maximize light output thus enabling a wider dynamic range. No matter what type of content is on, the W500 ensures that you get the very best viewing experience.
SenseyeT Clarity Enhancement
The W500 is designed to give you HD-quality video even when the source contains noise and is SD.
Go HD
The W500 not only converts SD content such as analog TV broadcasts to HD-quality video, it analyzes an amazing 1,024 pixels in the source for each pixel in the final HD version for native HD-like picture quality. |
 |
Stop the noise
The W500 analyzes multiple frames in source video to identify and then removes pixels giving rise to visual noise, and also corrects for distortions resulting from too much compression.
SenseyeT Motion Optimisation
The W500 remedies shortcomings in regular projectors when it comes to handling fast-changing video content. |
Make the "jaggies" go away
Sophisticated Multi-Dimensional Diagonal Filtering (MDDF) technology smoothes away the "jaggies" that crop up along the edges of moving objects-even those lying at shallow angles of 5° to 7° while regular filters can only handle larger angles from 30° to 45°. |
 |
 |
Look deeper
To remove artifacts around moving objects that result when converting interlaced SD video to non-interlaced HD video, the W500 examines twice as much data-four fields instead of the usual two-using advanced "motion-adaptive de-interlacing". |
SenseyeT Colour Management
Getting the widest possible range of colours and displaying them with precision accuracy is another key advantage of the W500.
Colour correctly
The W500 achieves greater colour accuracy by handling each colour signal in the video input individually, applying its brightness value directly in rendering the video. In contrast, regular projectors use a sampling process, which inevitably results in a loss of information about specific colour signals and colour distortion in the final projection image.
Features
– 3 LCD Projection System
– Native 16:9 720P Resolution
– 5000:1 Contrast Ratio
– Dynamic IRIS System
– 100”@3.3 m Throw Ratio
– HDMI Digital Input
– HD Ready
– Low Noise 27 dB
– Dust Proof with Air-Filter
– Horizontal and Vertical Lens Shift
– HQV™ (Hollywood Quality Video)
picture quality
– 3 User Menus |
|
Easy Installation and ease of use
Despite its rich feature set and flexible configuration options, the W500 makes getting things just right sublimely easy. And not only brings together the features you need, it's a genuine pleasure to use. It not only has lens shift allowing you to move the entire image left, right, up and down giving you a great amount of flexibility when installing but also has 2D keystone adjustment so that even an installation on an angle will still result in a perfect picture.
Have it all
The W500 gives you access to both newer digital and traditional analog video formats with its wide range of connection interfaces. |
 |
|
Specifications
Native Resolution |
1280 x 720 (16:9) |
Projection System |
3 x LCD |
Brightness |
1100 ANSI lumens |
Lamp |
140W, Up to 2000/3000 hours (Normal/Economic mode) |
Contrast Ratio |
5000:1 |
Weight |
3.9 kg (8.6 lbs) |
Noise Level |
31/27 dB (Normal/Economic mode) |
Resolutions Supported |
640 x 400 to 1920x1080 |
Dimensions (WxHxD) |
349 x 126 x 296 mm (W x H x D) |
Image Size |
23.5" to 300" |
Throw Ratio |
100"@3.3m (100"@10.8 feet) |
Zoom Ratio |
Manual Zoom 1.2:1 |
Lens |
F=1.6 to1.88, f=18.6(wide)~22.3mm(tele) |
Display Colours |
Full 16.7 million colour palette |
Aspect Ratio |
Native 16:9 (5 aspect ratio selectable) |
Horizontal Frequency (KHz) |
15~67 KHz |
Vertical Scan Rate |
50~100 Hz |
Projection Position |
Front/Rear, Table/Ceiling |
Input Terminals |
Analog RGB :D-sub x1
Digital: HDMI (with HDCP)x 1
Composite Video: RCA x 1
S-Video: Mini DIN 4 pin x 1
Component Video 1: RCA x 3
Component Video 2: RCA x 3
|
Output Terminals |
12 Volt Trigger |
Control Terminals |
RS232: Mini DIN 8 pin Control Port |
Product Colour |
White |
Video Compatibility |
NTSC, PAL, SECAM, SDTV, HDTV (480i, 480p, 576i, 576p, 720p, 1080i, 1080p) |
Auto Switching Power Supply |
100 to 240 V AC, 50 to 60 Hz |
Power Consumption |
Max 215W, 1.5W (Stand-by) |
On-Screen Display Language |
English/French/German/Italian/Spanish/Japanese/Russian/Dutch/Korean/ Czech/ Swedish/Polish/ Portuguese/ Thai/ Turkish/ Simplified Chinese/Traditional Chinese |
Preset Modes / Application Modes |
Cinema Mode
Dynamic Mode
Standard Mode
Photo Mode
3 User Memories |
Features |
HD ready
5000:1 contrast ratio
Dynamic IRIS system
HQV ( Hollywood Quality Video) picture quality
Horizontal and Vertical Lens Shift
HDMI digital AV input
User memory settings
BenQ proprietary Senseye Technology
Independent Colour adjustment |
Accessories (Standard) |
User Manual
Quick start card
Remote Control with batteries
User's Manual disk Power Cord
Component cable |
| Optional Accessories |
|
|
|
|
|
Lindy Premium Gold Component Video Cable, 75ohm OFC Coax |
Aus Wide Delivery: $13
|
|
Premium quality AV cable for home theatre interconnects!
High quality interconnect cable with 3 RCA colour coded plugs each end. Designed to connect any source with component level RGB outputs to projectors, TVs or other display devices.
- 3 x RCA Male to 3 x RCA Male
- 24K gold plated connectors
- 99.99% Oxygen Free Copper
- Low loss "LPDE" dialectric
- Aluminium screening foil
- Cable colour: Blue
- 25 year warrant |
|
|
Samsung BD-P1500 BLU-RAY Player |
With Projector Only
Normally $499
Delivery Add: $6
Pick Up Avail.
|
Experience the blu-ray difference with the SAMSUNG BD-P1500. You’ll get incredibly detailed images with brilliant color in full high definition 1080p resolution.
HD 1080P Blu-ray player- Compatible with BD-ROM/DVD-ROM/DVD-R/DVD-RW/AVCHD/Audio CD, Up-scale to 1080P, HDMI-CEC 1.3 and HD Audio
Code: DVD BD-P1500
|
|
|
|
Grandview Universal Projector Ceiling Mount |
Insured Delivery: $16
Pick Up Avail.
|
-Direct to ceiling mount
-Suits most projectors with 3 or 4 mounting holes
- GVMBC = BLACK
- GVMWC = WHITE
|
|
|
|
Grandview GVMBE & GVMWE Extension Pole for Grandview Mount. |
Insured Delivery: $16
Pick Up Avail.
|
- Suites the above Grandview projector mount
- Offers either a 500 or 1000mm drop.
- Available in white, silver and black
- GVMBE = BLACK
- GVMWE = WHITE
- (extension pole only, can only be used with above Hang It Ceiling mount) |
| |
|
|
|
|
