Sanyo PLV-Z700 Full High Definition Home Theatre Projector


DISCONTINUED
FOR CURRENT SANYO PROJECTORS CLICK HERE
Sanyo PLV-Z700 Reviews:


"The Image itself was excellent out of the box with a sharp picture and great colour reproduction. The unit performed well with DVD's, Bluray discs and the good old xbox 360 and is a very quiet unit at only 21dB. The only complaint we had here was the brightness of the image which will restrict its use to darker home theatre rooms and image sizes less than 140"(Which is still quite massive) or risk a washed out image.

Sanyo Oceania have recently added on an unprecedented 3 year warranty on the projector and one year on the lamp. This coupled with the the quality build expected from one of the few projectors still made in Japan makes the PLV-Z700 a top notch projector (As long as you get a genuine Australian unit). "



"There are five programmed color temperature options. From warmest to coldest they are Low 2, Low 1, Default, High 1 and High 2. On our test unit, Low 1 was the preferred setting for film, however, you can make whatever adjustments you want to that, or any of the programmed options. As with the Z2000, color accuracy on the Z700 is excellent. It is possible to dial in a picture averaging about 6500K with relatively uniform gray scale tracking."



  • Most affordable 1080p projector currently shipping (though competition at that price is on the way)
  • With minor performance compromise in "best mode", average or slightly above average brightness
  • Very good, post calibration
  • Sharper than most, image
  • Really good shadow detail
  • Dynamic irises on image and lamp, for improved black level performance
  • Extensive selection of image enhancement processing capabilities
  • Good image noise performance
  • Better performance than many on SD-TV sources
  • Performed very well on HDTV and hi-def sports, in particular
  • Very good remote control
  • Very quiet operation
  • Three year warranty

FULL HIGH-DEFINITION RESOLUTION – 1080p
Not only is it full HD (1920 x 1080), the PLV-Z700 achieves deep, rich, and very importantly, accurate color. This is automatically accomplished thanks to SANYO’s exclusive TopazReal HD Technology, a 3D color management system that addresses color phase and color level to obtain perfect color reproduction. The PLV-700’s color management system can generate a total of approximately 216 billion possible color combinations. This new color management system was designed to optimize the potential of deep color from either of the projector’s two HDMI inputs.

14-Bit Gamma and High-Quality Image Processing Circuitry
Burgundy, vermilion, scarlet, crimson, rose—there are countless shades of red. That's why the ability to express details is essential to delivering a truly high-quality image. In the Z700 series, 12-bit processing is used at each imaging stage and 14-bit processing is used for gamma correction. This advanced circuitry achieves smooth gradation for beautiful shading.

LENS MAXIMIZATION OF IMAGE DETAIL
Rated at 1200 lumens, the PLV-Z700 is capable of an incredible 10,000:1 contrast ratio for superlative black levels, even in ambient light. Plus it has a newly-developed, high-efficiency lens that maximizes image details for exceptional optical performance.

RealFocus Full HD Lens
In developing the Z700, SANYO paid utmost attention to lens performance. The result is a new high-resolution lens that delivers every piece of information embedded in full-HD video. Thanks to an extra-low-dispersion (ED) lens and aspherical lens elements, this advanced lens system dramatically reduces chromatic aberration to ensure optimal display of full-HD images. The lens also provides sharp focusing all the way to the image edges.

ADVANCED LENS SHIFT FOR VARIOUS ROOM ENVIRONMENTS
The PLV-Z700 is outfitted with the industry’s most advanced lens shifting function. When coupled with the projector’s short throw capability and 2x zoom, the PLV-700 can create a large screen image in any size room and from virtually any location. The lens shifting function allows wide-range shifting up or down to three screen sizes and left to right to two screen sizes. The throw design of the PLV-Z700, which is capable of projecting a 100-inch diagonal image from 10 to 20 feet away, makes it extremely suitable for small to mid-size home theaters.




VIRTUALLY SILENT FAN DESIGN
A 1200 lumen projector generates a tremendous amount of heat and requires a high quality fan to ensure proper operation. At this level of brightness, the fan is ‘on’ most of the time and the noise can be extremely loud and disruptive, especially in smaller home theaters where the projector and the audience are in the same vicinity. To promote greater enjoyment of the film and to
reduce noise levels during quiet passages of a film, the PLV-Z700 is equipped with the industry’s quietest fan, a large aperture, low noise Sirocco cooling fan that never rises above 21dB in the economy mode.


3D Color Management
This function lets you pause the picture and adjust the color tone of a selected part of the image. For example, you can make an actor's skin appear a little brighter. Using the level, hue and gamma axes, it's easy to ne-tune the picture. You can register up to eight adjustment results for later use.

Advanced Mode
Designed for the most avid movie fans, this mode lets you nely adjust each picture setting yourself, rather than using a preset mode. There's a huge number of adjustment combinations possible, so you can get the picture exactly the way you want it. And you can store up to seven combinations of settings in memory for recall at a later time.

Seven One-Touch Preset Modes
The Z700 offers seven preset modes, each of which provides the optimal color balance for a specic viewing environment and video source. Just select the appropriate mode, and the Z700 is ready to deliver clear, detailed images that are rich in beauty and emotion.





Motor-Operated Slide Shutter
The shutter can be opened or closed automatically by remote control. This means you will no longer have to manually attach or remove the lens cap when the projector is mounted on the ceiling or in a high location that is dicult to reach. The shutter also protects the

Lens Shift and Dial Lock
The horizontal and vertical lens shift function, which can be adjusted using two small wheels on the side of the projector, allows you to adjust the screen projection easily, without having to move the actual body of the projector. This shift function does not cause any keystone (trapezoidal) distortion in the image, so even a rst-time user will nd it easy to use. There's also a lock mechanism provided. Once you get the projection the way you want it, you can lock the system in place.

Multifunction Remote Control with Full Light-Up Function
We carefully chose the size of the remote control and the key layout for easy, intuitive use. All keys are illuminated, so the projector is easy to operate even in the dark. And to accommodate people who like to tweak the picture adjustments all the time, the remote control has keys that let you directly select a video mode and adjust the settings.


Easy Maintenance
A The lamp can be accessed from the back of projector, so you can replace one without taking the projector down from the ceiling.

B In the bottom of the projector there's a special maintenance hole—a SANYO original—that you can use to remove any dust adhering to the LCD panel. Just use the blower provided.
C There's also a large, high-density pleated electrostatic air lter at the cooling air inlet to keep dust out.

Two HDMI™ Inputs
With two sets of HDMI™ ( ver 1.3b Deep Color) terminals, the Z700 comes equipped to provide the best image quality possible from today's and tomorrow's high-end video sources.
The two terminals let you connect two HDMI-enabled devices, such as a next-generation DVD player and an HD recorder or video game machine, without reconnecting cables.


Specifications

Model number PLV-Z700
System RGB liquid crystal shutter protection system
Optical system Dichroic mirror separation / Prism synthesis system

LCD Panel

Size 0.74 inch x 3, Aspect Ratio 16:9 (Organic LCD panel)
Drive System Polysilicon TFT Active Iris
Pixel Count 2,073,600 (1920 x 1080) x 3 ; Total pixels 6,220,800
Pixel Array Stripe
Projection Lens Manual Zoom (1-2.0x) f=22.6-45.3mm, F2.0-F3.0
Light Source 165 W UHP Lamp
Screen Size*1
(Projection Distance)
Minimum 40” - Maximum 300”
(approx.1.2 to 18.4m)
Color Reproducibility Full color (1.07 billion colors)
Brightness*2 1,200 ANSI lumens*3
Uniformity*2 85%*4
Contrast Ratio*2
(Full On/Full Off)
10000:1*5
Noise Output*2 Approx. 21dBA (Lamp mode : Eco)*6
Scanning Frequency Horizontal: 15-80KHz, Vertical: 50-100Hz, Dot Clock: 100 MHz or less

Terminals

PC Input Analog RGB input x 1 ; Mini D-sub 15-pin x 1
Video Input
Digital input (x2);     HDMI x 2 [HDMI 1.3b (Deep Color) compatible]
Component input (x2);     3RCA (Y/Cb/Cr)x2
S-video input (x1);     S-video x 1
Composite input (x1);     RCA x 1
Controller
input/output,
and other
Service port ; Mini DIN 8-pin x 1 (for service-use)
Power switch ON/OFF (see-saw switch)
Operating Temperature 5 ~ 35℃
Power Source AC 100~120V、AC200~240V(±10%), 50/60 Hz
Power Consumption 246W
Dimensions 400.0 (w) x 146.0 (h) x 346.0 (d) (including protruding parts)
Weight 7.5kg
Main Accessories
Wireless remote control (AA battery x2)
Removable power cord
Operating manual
Warranty

Supplied Accessories
Remote
Rear Panel
Optional Accessories

Extended Warranty
All Programs come with:
- United ID Sticker (must be attached to product)
- United Certificate with Terms & Conditions

Program Coverage:
- LCD & DMD pixels are covered only as per original manufacturer's pixel terms & conditions
- Does not cover Cords, Power Adapter
- Does not cover consumable items such as projector globes
+ 2 Year On-Site Extended Warranty (up to 5 years total) $249
+ 1 Year On-Site Extended Warranty $190


Grandview GVFB102H Fixed Frame Home Theatre Screen

Your Price:
$599

With Projector Only
Normally $649

Delivery Add: $6
Pick Up Avail.


- Great for television, video's and data projection
- Designed especially for wide screen HDTV and Movies
- Matt White American PVC material for accurate colour reproduction.
- Black border for sharp image edges and sleek modern look.
- 2250W x 1265H Image size
- 1:1 Gain
- Check out the full range of screens here


Samsung BD-D5500 3D BLU-RAY Player

Your Price:
$249

With Projector Only
Normally $299

Delivery Add: $6
Pick Up Avail.


Experience the blu-ray difference with the SAMSUNG BD-D5500. You’ll get incredibly detailed images with brilliant color in full high definition 1080p resolution.

Web-Connected Samsung Apps Wireless Ready (Adaptor not included) Full HD 1080p and 1080p up-conversion Sync with multiple devices using AllShare



Lindy Premium Gold Component Video Cable, 75ohm OFC Coax

5Metres
$79.95
10Metres
$104.95
15Metres
$134.95
20Metres
$169.95

Aus Wide Delivery: $13


Premium quality AV cable for home theatre interconnects!

High quality interconnect cable with 3 RCA colour coded plugs each end. Designed to connect any source with component level RGB outputs to projectors, TVs or other display devices.

- 3 x RCA Male to 3 x RCA Male
- 24K gold plated connectors
- 99.99% Oxygen Free Copper
- Low loss "LPDE" dialectric
- Aluminium screening foil
- Cable colour: Blue
- 25 year warrant



Premium VGA Monitor Cable (15HDM/15HDM)

5 metres
$29.95
10 metres
$59.95
15 metres
$69.95
20 metres
$89.95
30 metres
$110.95


Aus Wide Delivery: $15

Heavily shielded coaxial RGB cable giving you a crisper display at higher resolutions!

. Features UL Approved Cabling
. Filters included on both ends cutting down on noise
. Maintains stronger signals using a shielded cabling run.
. Comes in 15pin D-sub format with Male to Male conectors

Click for more cables
