Sanyo PLC-XU300A High Brightness Digital LCD Projector |
|
 |
FOR CURRENT SANYO PROJECTORS CLICK HERE |
Bright mobile projector with easy set-up function.
Automatic set-up enables operation within seconds |
Black-board mode for optimised projections onto coloured surfaces (e.g. interactive whiteboards) |
Security features: PIN code lock, key lock function |
Brightness: 3,000 ANSI lumens, contrast ratio: 500:1 |
XGA Resolution (1,024 x 768 pixels) in 4:3 format |
Fan Noise: 29 dB (eco mode) |
COMPLETE EASY AUTO SET UP FUNCTION, SMART AUTO INPUT
SEARCH AND AUTO VERTICAL KEYSTONE CORRECTION
PLC-XU300 provides "Auto Set Up Function" that corrects keystone shaped
distortion by searching for an input signal and detecting projector incline,
therefore reducing set up time. PLC-XU300 automatically compensates for
keystone picture distortion. Auto Keystone Correction, Auto Input Search and
Auto PC Adjustment make it a really smart projector.

NETWORKING CAPABILITY
Bright 3000Im, the PLC-XU300 is equipped with SANYO’s exclusive PJ-Net
Master Network Interface software for wired and wireless networking, a
common feature among SANYO’s extensive line of commercial projectors.
Networking allows the monitoring of projector functions and operation from a
long distance via a web browser for up 15,000 Sanyo projectors. Emails can
be sent automatically to report operating status.
SHORT THROW LENS WITH 1.2 ZOOM AND 1W SPEAKER
PLC-XU300 is equipped with a zoom lens that allows screen size adjustment.
The optical zoom works to maintain the image quality. The short-focus type
lens allows large screen image projections with a short throw distance. The
PLC-XU300 enables 100-inch screen projection at the shortest distance, 83
inches. Along with its mobility, the PLC-XU300 features a high-output 1 Watt
speaker. Sufficient audio is delivered through its built-in speaker, so the
projector can be used in small conference rooms, classrooms, and other
similar spaces.
BLACK BOARD / COLOR BOARD MODE
What could be more right for education? A black board mode. The PLCXU300
is compatible with four colored (red, blue, green and yellow) projection
surfaces via the ‘Color Board Mode’. It adjusts the color to make images look
as true as on an ordinary white screen.

LAMP REPLACEMENT ON TOP CABINET
There is access to the lamp from the top of the projector which means you can
replace the lamp on a ceiling-mounted unit without taking down the projector.
CLOSED CAPTION
PLC-XU300 Closed Caption compatible.
|
Specifications
Type |
3.0 x 0.63" TFT p-Si (4:3), micro lens |
No. of pixels |
2,359,296 (1024 x 768 dots) |
Lamp wattage |
225 W |
Brightness (typical)*1 |
3000 lumens |
Contrast ratio |
500:1 |
Uniformity |
85% (corner to center) |
Standard lens |
F1.6-1.76, f=22.3-26.8mm (0.8-1.1 inch) |
Screen size |
40"-300": 1.4m-12.7m; 100": 3.5-4.2m |
Zoom/focus |
1:1.2 manual driven, U:D = 9.1 |
SDTV/HDTV signals |
480i, 480p, 575i, 575p, 720p, 1035i, 1080i |
Colour systems |
PAL, SECAM, NTSC, NTSC4.43, PAL-M, PAL-N |
Video signal |
S-video, Composite, D-sub 15pin for Component |
Terminal |
RCA:Video; Mini-DIN 4-pin: S-video; D-sub 15: Component |
Computer compatibility |
UXGA/SXGA/WXGA/XGA/SVGA/VGA/MAC |
Terminal |
D-sub 15, D-sub 15 for input or Monitor out |
Audio |
RCA (L/R) for video input; Mini-jack x 2 (stereo) for computer input; Mini-jack (stereo) for output (variable) |
Communication Terminal |
Dsub-9 for control port (RS-232C), RJ-45 for LAN |
Presentation Tool |
Freeze, Digital zoom, No show |
Other features |
Progressive, 3-2 & 2-2 pull down, LTI & CTI*2, User logo |
Scanning frequency |
H/V sync 15-100 kHz, 50-100 Hz; Dot clock 140 MHz |
Sound output |
1.0W Mono |
Fan noise |
29dBA (eco mode) |
Voltage |
100-240V AC (auto voltage) |
Power consumption |
100-20V AC |
300W (normal), 237W (eco mode), 2.3W (stand-by eco mode) |
200-240V AC |
287W (normal), 225W (eco mode), 3.2W (stand-by eco mode) |
|
Dimensions (W x H x D) |
326 x 83.1 x 231.6mm |
Net weight |
2.6kg |
Standard Accessories |
Quick reference guide, User's manual (CD-ROM), CD-ROM read me note, PIN code label, Computer cable (D-sub 15-Dsub-15), Remote control, AAA battery x 2, Strap for lens cap |
