Optoma WU515T DLP Full HD High Brightness Projector
|
|
|


 |


 |

|
FOR THE CURRENT RANGE OF OPTOMA PROJECTORS CLICK HERE |
Quick Facts: |
|
Optoma WU515T Throw Distance Chart (Examples for common Sizes) T/R: 1.26-2.16:1 |
Image Size |
Installation Distance (Approx. To Lens) |
83" (16:10) 1790x1120mm |
From 2.3m to 3.9m |
98" (16:10) 2110x1320mm |
From 2.7m to 4.6m |
118" (16:10) 2540x1590mm |
From 3.2m to 5.5m |
|
SPECIFICATIONS
Native Resolution: WUXGA 1920 x 1200 16:10
Brightness: 6000 ANSI Lumens
Maximum Contrast: 10,000:1
Weight: 5.9kg
Fan Noise: 28db (eco)
Warranty: 3 Years (+1 Year $159)
Lamp Warranty: 12months/1000hrs
Lamp Life Up To: 5,000hrs |
FEATURES
- Horizontal & Vertical Lens Shift
- Horizontal & Vertical Keystone
- 2x HDMI Connection
- MHL Compatible
- 1.8x Zoom
- Powerful 20W Speaker
- 3D Capable(3D glasses required)
- HDBaseT Compatible |
Optoma WU515T
High Resolution WUXGA Projector
- 4 corner Geometric Correction for easy installation of basic stacking solutions or on uneven walls
- 1.8x Zoom - excellent image from a short or long distance
- Vertical/ Horizontal keystone and lens shift for various applications
- Bright Projection at 6000 ANSI lumens for large installations
- Full Control over LAN and RS-232 using Crestron, IP Link, Extron PJ-Link, and Telnet
- Built-in HDBaseT ideal for long cable runs in the install environment
The Optoma WU515T is a WUXGA professional Installation projector, ideal for corporate environments, house of worship and Pro-AV installs. WU515T DLP technology provides accurate colors and great contrast for dark and white images. This great projector is furnished with advanced features to facilitate a quick installation.
Features include: Four corner correction (ideal for image stacking or uneven walls) , Horizontal and Vertical Lens shift and Keystone together with x1.8 zoom ratio, permit an quick setup and easy usability from any angle.
Equipped with a variety of inputs, including HDBaseT, HDMI built in MHL technology, allows you to connect to a wide variety of HD devices to easily display your content. In addition, the environmentally friendly WU515T has energy saving features including Eco+ lamp power management, <0.5W standby mode and auto power off, saving you both time and money by prolonging your lamp life.
Full HD WUXGA
Full HD (1920 x 1200) has more than twice the resolution of HD Ready (1280 x 720). WU515T is compatible with HDTV broadcasts and high-definition media to project impressive full 1080p images and video in their original digital brilliance
High Contrast
Add more depth to your image with a high contrast projector; with brighter whites and ultra-rich blacks, images come alive and text appears crisp and clear - ideal for business and education applications. |
 |
 |
Full 3D
Optoma projectors can display true 3D content from almost any 3D source, including 3D Blu-ray players, 3D broadcasting and the latest generation games consoles. Support for 144Hz rapid refresh rate provides ultra-smooth flicker free images. |
Integrated speaker
The built-in speaker offers excellent audio support. Easy to set up without the need for costly external speakers.
Energy saving
Using the specially designed lamp modes, you can reduce the power consumption by up to 70%. Each mode also has a positive effect on the lamp life, while lowering the total cost of ownership and reducing maintenance.
Auto power off
There may be instances when the projector is left running when not in use. To help save energy, the "Auto Power Off" feature automatically turns off the projector after a set period of time if it is not being used.
Eco AV mute
Stay in control of your presentation with Eco AV mute. Direct your audience's attention away from the screen by blanking the image when no longer needed. This also reduces the power consumption by up to 70%, further prolonging the life of your lamp.
PureShift
Simplify installation with PureShift, which provides a wide range of projector placement possibilities.
Four-corner adjustment
Individually warp each corner of the image to create a perfectly square image. Ideal for image stacking, uneven walls or where projector placement is awkward and needs to be installed at an angle.
Brightness matching
The brightness of a projector will vary throughout its life. To correctly match multiple units, the projector has set lamp power modes (stepped lamp dimming) to help match the brightness of both projectors.
MHL
Turn your projector into a smart display by connecting your smartphone or tablet with a single cable using MHL, enabling you to view presentations and documents, stream videos and share photos on the big screen.
Large zoom range
A large zoom range enables multiple placement possibilities at a variety of distances from the projection screen. An advantage to this is that expensive interchangeable lens projectors can be substituted with a more cost effective solution whilst still retaining a diverse choice of positioning options.
Long lamp life
Reduce the number of lamp changes with long lamp life
Networking and control
Featuring a wide range of options you can remotely control and monitor the projector.
RS232
Optoma projector’s come with an extensive set of RS232 commands making it simple and easy to manage using any control system.
AMX Compatibility
Dynamic discovery protocol is incorporated into the projector allowing for easy installation with AMX control systems.
LAN Control
- Using the compatible RoomView® software you can power on/off, monitor, manage and control up to 250 projectors at the same time from any computer.
- Schedule the projectors to power on/off.
- Control and alter the projector settings using the simple web browser.
- Emergency text broadcast capabilities for urgent or important announcements.
- Automatically receive email updates for lamp maintenance.
Amazing Colours
For vibrant, natural looking images, Optoma projectors incorporate BrilliantColor™ multi-colour processing technology. |
 |
Color Guarantee
Enjoy dazzling colours for years to come; guaranteed by Optoma for five years’ consistent performance. |
 |
Quick resume
This feature allows the projector to be instantly powered on again, if it is accidentally switched off.
USB power
Use the USB-Power to power an HDMI dongle, such as Google Chromecast or the Optoma WHD200 wireless HDMI device.
Image stacking
Double your image brightness without significantly increasing your installation cost; with warp adjustment, you can achieve any brightness you want. Image stacking permits flexible installations and greater redundancy; an image can be displayed without interruption while swapping lamps. Alternatively, images can be realigned to be perfectly square if aligned beyond the lens shift range.
Wired remote
The wired remote connection allows all aspects of the projector to be individually controlled without requiring a line-of-sight to the projector; invaluable when using multiple units during live events.
HDBaseT
Simplify installation by transmitting uncompressed HD video, audio, Ethernet and control commands using a standard LAN cable of up to 100m.
|
Specifications
Display Technology |
Single 0.67" WUXGA chip, DLP® Technology by Texas Instruments™ |
Native Resolution |
WUXGA 1920 x 1200 |
Brightness |
6000 ANSI Lumens |
Contrast Ratio |
10,000:1 (full on/full off) |
Noise Level (Eco mode) |
28 dB |
Weight |
13 lbs (5.9 kg) |
I/O Connectors |
1x HDBaseT, 1x Display port, 2x HDMI 1.4a + MHL, 2x VGA-In, 1x VGA out, Composite Video, S-Video, 3x Audio-In (stereo, 3.5mm and RCA), 1x Audio-Out (3.5mm jack), 1x Mic in (3.5mm jack), 12v trigger, USB type-A 5V, 3D Sync vesa port, RS-232C, mini-USB (service/control), RJ45, AC power (3 pin) |
Maximum Resolution |
WUXGA (1920 x 1200) |
Computer Compatibility |
UXGA, SXGA, XGA, SVGA, VGA, WXGA, HD, Mac |
Video Compatibility |
PAL (B, D, G, H, I, M, N, 4.43MHz), NTSC (M, J, 3.58MHz, 4.443MHz), SECAM (B, D, G, K, K1, L, 4.25,MHz, 4.4MHz, 480i/p, 576i/p, 720p(50/60Hz), 1080i(50/60Hz) 1080p(24/50/60Hz) |
Displayable Colors |
1.07 Billion |
Projection Lens |
F=17.63~31.36 mm; manual focus |
Throw Ratio 3 |
1.26:1~2.16:1 |
Projection Screen Size |
27.9"~301.8" (0.71~7.66 m) diagonal 16:9 |
Projection Distance |
4.26'–25.59' (1.3–7.8 m) |
Zoom Type |
1.8x Manual zoom |
Aspect Ratio |
16:10 (Native), 4:3, Auto |
Offset |
100% (±5% Variance) |
Horizontal Scan Rate |
15.375~91.146 KHz |
Vertical Scan Rate |
24– 85 Hz (120 Hz for 3D feature projector) |
Lamp Type |
365W |
Lamp Life2 Eco/Bright |
5000/3000 (hrs) |
Keystone Correction |
± 30° Vertical ± 30° Horizontal |
Audio |
20-Watt |
Dimensions (W x H x D) |
16.7" x 6.3" x 13.5" (424 x 160 x 344 mm) |
Remote Control |
IR and wired control |
Power Supply |
AC input 100–240V, 50–60 Hz, auto-switching |
Power Consumption |
445W (Bright), 335W Max (ECO), <0.5W (Standby) |
Operating Conditions |
41–113°F (5~45°C), 85% max humidity |
Uniformity |
80% |
Security |
Kensington® lock port, security bar, password protection |
Standard Accessories |
WU515 projector, AC power cord, VGA cable, remote control, batteries, multilingual CD-ROM user’s manual, basic user manual, and warranty card |
Optional Accessories |
Universal ceiling mount, Optoma screen, DLP® Link™ 3D glasses, wireless HDMI system |
RoHS |
Compliant |
Lens Shift |
Vertical: +20%; Horizontal: ±10%(constraints apply see user manual for details) |
3D Support |
Full 3D - The 3D features of Optoma projectors can only be used with compatible 3D content. Typical applications include use with 3D educational or 3D design and modelling systems. 3D TV broadcast systems, (SKY in the UK), Blu-ray 3D™ and 3D games from the Sony® PS3 or Microsoft® Xbox 360 are now supported as part of the HDMI v1.4a specification. |
3D Compatibility |
Side-by-Side:1080i(50/60Hz)
Frame-pack: 1080p(24Hz), 720p(50/60Hz)
Over-Under: 1080p(24Hz), 1080i(50/60Hz), 720p(50/60Hz)
3D glasses are needed and are sold separately.
Refer to user manual for details. |
Speaker (Watts) |
Two 10-Watt (stereo) |
Color Wheel |
6 Segment; RYGCWB |
360’ Operation |
Not supported |
Portrait Mode |
Not supported |
Features |
V/HLens Shift, Crestron RoomView®, PJ-Link |
Warranty |
3-Year |
Projection method |
Front, rear, ceiling mount, table top |
Supplied Accessories
|
Remote |
|
|
|
|
 |
