| Optoma EX536 DLP Portable Projector |
|
|
 |
|
| |
 |
FOR CURRENT OPTOMA PROJECTORS CLICK HERE |
 |
 |
- Bright projection – 2800 ANSI Lumens
- XGA resolution, 3000:1 contrast ratio for
sharp, detailed presentations and graphics
- Energy saving <1W standby mode
- Security bar and password protection
for added security
- RS232 for meeting room control systems
- Low ownership costs – up to 4000hrs lamp life
- Portable – carry bag provided for easy transportation
- DLP® filter-free design – Virtually no maintenance
2800 ANSI Lumens & 3000:1 Native High Contrast
Brilliant optical design makes EX536 exceptional in providing high brightness & crystal-clear native high contrast, ideal for classrooms/ conference rooms with a capacity of 20–40 people.
 |
AMAZING COLOURs
The EX536 incorporates BrilliantColor™ technology to produce
stunningly bright images with perfectly balanced life-like colours.
Preset display modes allow you to achieve a perfect image on a variety
of surfaces including screens and interactive whiteboards. |
1.07 Billion Display Colors
Incorporated with Texas Instruments’ latest DDP2431 scaler to realize true 10-bit signal processing. The new 10 bit color processing technology increases the number colors that can be display from 134.2 million to 1.07 billion, presenting more natural and vibrant pictures.
TrueVivid™ Technology
Optoma proprietary TrueVivid™ color enhancement technology affords better balanced chrominance and luminance for life-like colors. giving the viewer the ultimate visual experience.
Remote Management
Control plural EX536 by wire via directly or RS-232 hub with projector ID in EX536
Unsurpassed Product Quality/ Reliability
- Long-life lamp (3000/4000 hrs)
- Lowest cost of owership
- Hassle free/ filter free/ minimum maintenance required
|
|
|
Specifications
| Display Technology |
Texas Instruments DLP® technology/
0.55'' XGA DC3 DMD Chip |
| Resolution |
Native: XGA (1024 x 768)
Max: UXGA (1600 x 1200) 60Hz |
| Brightness (typical) |
2800 ANSI Lumens |
| Contrast Ratio |
3000:1 |
| Displayable Colors |
1.07 billion colors |
| Projection Lens |
F = 2.41 ~ 2.55, f = 21.8 ~ 24 mm; 1.1x manual zoom / focus lens |
| Image Size |
22.9 to 302.85 inches |
| Projection Distance |
1.0 ~ 12m |
| Throw Ratio |
1.95 ~ 2.15:1 |
| Digital Keystone Correction |
± 40° Vertical |
| Aspect Ratio |
4:3 Native, 16:9 Compatible |
| Scan Rate |
Horizontal : 15.3 ~91.1 KHz /
Vertical : 24 ~85 Hz |
| Computer Compatibility |
UXGA, SXGA+, SXGA, XGA, SVGA, VGA Compression, VESA standards
PC & Macintosh compatible
|
| Video Compatibility |
HDTV (720p, 1080i/p), SDTV (480i/p, 576i/p)
Full NTSC, PAL PAL-M, PAL-N, SECAM
|
| Input / Output Terminals |
VGA(VGA/YPbPr/ RGB/SCART) x2
S-Video x1
Composite x1
Audio input x1
Audio output x1
VGA output for monitor loop throughx1
RS232 Control interface x1
IR receiver (Front & Back) x2 |
| Speaker |
2W speaker x 1 |
| Uniformity |
85 % |
| Noise |
28dB(STD mode) |
| Lamp Type |
185-watt user replaceable lamp |
| Lamp Life |
4000 hours (STD mode)
3000 hours (Bright mode) |
| Power Supply |
AC 100 ~ 240 V, 50/60 Hz |
| Dimensions (W x D x H) |
286 x 192 x 97 mm |
| Weight |
2.3 kg / 5.0 lbs |
Supplied Accessories
|
Carry Bag |
Remote |
|
|
| Optional Accessories |
|
|
| |
Extended Warranty
|
Program Coverage:
- LCD & DMD pixels are covered only as per original manufacturer's pixel terms & conditions
- Does not cover Cords, Power Adapter
- Does not cover consumable items such as projector globes |
| + 2 Year On-Site Extended Warranty (5 Year Total) |
$139 |
| + 1 Year On-Site Extended Warranty |
$110 |
|
|
|
