Optoma ES526 DLP Portable Projector



DISCONTINUED

FOR CURRENT OPTOMA PROJECTORS CLICK HERE


  • Bright projection – 2800 ANSI LumensSVGA resolution, 3000:1 contrast ratio for
    sharp, detailed presentations and graphics
    Energy saving <1W standby mode
    Security bar and password protection
    for added security
    RS232 for meeting room control systems
    Low ownership costs – up to 4000hrs lamp life
    Portable – carry bag provided for easy transportation
  • DLP® filter-free design – Virtually no maintenance

Immaculate Image Quality
From boardroom to classroom, the ES526 delivers bright, high contrast presentations and images with crystal
clarity. Vibrant, life-like colours using BrilliantColor™ technology will ensure your audience is left speechless every
time the ES526 is turned on. The environmentally friendly ES526 has energy saving features including <1W standby mode. Long lamp-life
of 4000hrs combined with our unique Optoma Colour guarantee saves you both time and money whilst ensuring
hassle-free, long lasting projection.Clear, Focused Images
Technology from Texas Instruments produces a stunning 3000:1 contrast ratio for pin sharp graphics and crystal clear text. Crisper whites, ultra-rich blacks makes images come alive and text

Main ten ance FREE = Lower Total Cost of Ownership (TCO)
DLP® technology ensures lower cost of ownership, longer life and improved reliability compared to other technologies.
The filter-free projector design means no more regular filter cleaning or replacements, saving you time and money.

AMAZING COLOURs
The ES526 incorporates BrilliantColor™ technology to produce stunningly bright images with perfectly balanced life-like colours. Preset display modes allow you to achieve a perfect image on a variety of surfaces including screens and interactive whiteboards.

Time and Energy Savings
The ES526 incorporates energy saving features to conserve power and extend the lamp life:
The timer control functions can automatically switch the projector off to standby mode <1W, conserving power and extending the lamp life to an astonishing 4000 hours**. It takes less than 10 seconds for the projector to power up and shutdown, so the ES526 not only saves time but energy too.

CONTROL
The extensive RS232 command set makes it simple and easy
to control the ES526 with any control system.

AMX Compatibility – Dynamic Discovery Protocol is incorporated into the ES526. This feature allows for easy installation with AMX control systems.

Smooth, Seamless Projection
Even in the fastest moving scenes, the ES526 will project a smooth and seamless image. The rapid response of DLP® technology ensures that the projected movie or video game remains perfect and precise.



FEATUR ES
 6 preset display modes
 Quick keystone correction
 Security bar and password protection for added security
 Easy to use remote with direct source control




Specifications

Display Technology Texas Instruments DLP® technology/
0.55'' SVGA DC3 DMD Chip
Resolution Native: SVGA(800 x 600)
Max: UXGA (1600 x 1200) 60Hz
Brightness (typical) 2800 ANSI Lumens
Contrast Ratio 3000:1
Displayable Colors 1.07 billion colors
Projection Lens F = 2.41 ~ 2.55, f = 21.8 ~ 24 mm;
1.1x manual zoom / focus lens
Image Size 22.9 to 302.85 inches
Projection Distance 1.0 ~ 12m
Throw Ratio 1.95 ~ 2.15:1
Digital Keystone Correction ± 40° Vertical
Aspect Ratio 4:3 Native, 16:9 Compatible
Scan Rate Horizontal : 15.3 ~91.1 KHz /
Vertical : 24 ~85 Hz
Computer Compatibility UXGA, SXGA+, SXGA, XGA, SVGA, VGA Compression, VESA standards
PC & Macintosh compatible
Video Compatibility HDTV (720p, 1080i/p), SDTV (480i/p, 576i/p)
Full NTSC, PAL PAL-M, PAL-N, SECAM
Input / Output Terminals VGA(VGA/YPbPr/ RGB/SCART) x1
S-Video x1
Composite x1
Audio input x1
Audio output x1
VGA output for monitor loop throughx1
RS232 Control interface x1
IR receiver (Front & Back) x2
Speaker 2W speaker x 1
Uniformity 85 %
Noise 28dB(STD mode)
Lamp Type 185-watt user replaceable lamp
Lamp Life 4000 hours (STD mode)
3000 hours (Bright mode)
Power Supply AC 100 ~ 240 V, 50/60 Hz
Dimensions (W x D x H) 286 x 192 x 97 mm
Weight 2.3 kg / 5.0 lbs
Supplied Accessories
Carry Bag
Remote
Rear Panel

Optional Accessories

Viewsonic WPG-350 Wireless Presentation Gateway
