Long Lamp Life at up to 6000 hours
Enjoy a lamp life performance of up to 6000 hours* – twice the lamp life expectancy of average projector lamps on the market! This certainly lowers the number of lamp changes and keeps all maintenance to a minimum.
*when used in Economic mode.
Visual Excellence
Sharpen up with high contrast ratios
The MX511 boasts high contrast ration with 3000:1. High contract ratios translate to razor-sharp detail definition and a broader range of subtle color differences, which makes text is sharper, cleaner, and easy to read.
2700 ANSI lumen brightness
A mainstream standard 2700 ANSI lumen projection lamp ensures great viewing for small-mudiem size rooms even in locations with ambient light, so your hard works can always be presented as good as can be.
Thoughtful Features
Comprehensive Connectivity with HDMI
MX511 features one HDMI port can be plugged with digital devices such as Blue-ray player, laptop...etc. HDMI is also the highest and completely future-proof connection standard, ensuring pure digital audio and video perfection.
Built-in Speakers
With built-in 2W speaker with the MX511, not only do you get the vivid visual performance, you get the same audio satisfaction, too!
Multi-Function Connectors
Specifications
Projection System
DLP® technology by Texas Instruments®
Native Resolution
XGA (1024 x 768)
Brightness
2700 ANSI lumens
Contrast Ratio
3000:1 (Full on/Full off)
Color
Full 1.07 billion color palette
Lens
F= 2.51 to 2.69, f= 21.95 ~ 24.18 mm
Aspect Ratio
4:3 Native, 16:9 Selectable
Throw Ratio
1.97-2.17 (50"@ 2m)
Image Size (Diagonal)
23” to 300”
Zoom Ratio
Manual Zoom, 1.10:1
Lamp
190W, 4500/6000 hours (Normal/Economic mode)
Keystone
Manual Vertical ±40°
Horizontal Frequency
31-90 kHz
Vertical Scan Rate
50-120 Hz
Computer Compatibility
VGA(640 x 480) to UXGA(1600 x 1200)
Dimensions(W x H x D)
265 x 100 x 210 mm r(10.4 x 3.9 x 8.3 inch)
HDTV Compatibility
480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Video Compatibility
NTSC, PAL, SECAM
Input Terminals
PC:
Analog RGB: D-sub 15 pin x 2 A/V:
HDMI V1.3 x 1
Component Video: D-sub 15 pin x 2
(Shared with Analog RGB connector)
S-Video: Mini Din 4 pin x 1
Composite Video: RCA x 1 Audi:
Stereo Mini Jack x 1
Output Terminals
PC:
Monitor Out: D-sub 15 pin x 1 Audi:
Variable Audio Out : Stereo Mini Jack x 1 o:
Speaker: 2W x 1
SPECIFICATIONS
• Soft Carry Case with Padding
• Shoulder strap, carry handle, and cable pocket included
• Fits most BenQ Projectors
Universal Flush Projector Ceiling Mount FB-1*Recommended*
Your Price:
$149
SPECIFICATIONS
Available in BLACK (FB-1B) and WHITE (FB-1W)
• Swivel: 360°, Adjustable roll, pitch and yaw.
• Rigid Steel construction.
• Durable powder-coated finish (Black or White).
• Supports up to 10kgs.
• Mounting hardware included.
• User manual included.
• All bracket models come standard with 4 x mounting arms.
FEATURES
- Direct to ceiling mount (150mm)
-
Suits most projectors with 3 or 4 holes
Premium HDMI Digital AV Cable
2 Metres
$29.95
5 Metres
$49.95
10 Metres
$79.95
15 Metres
$99.95
Premium quality AV cable for use with HDMI enabled digital displays, projectors, LCD screens and Plasma TVs!
- HDMI 1.3 with an increased single-link bandwidth to 340 MHz (10.2 Gbps) to support the demands of future HD display devices
- Compatible with HDTV and HDCP (High-Bandwidth Digital Content Protection)
-
Connectors: HDMI Male/Male, Type A
-
10 year warranty
Premium VGA Monitor Cable
5 Metres
$29.95
10 Metres
$59.95
15 Metres
$69.95
20 Metres
$89.95
30 Metres
$110.95
Heavily shielded coaxial RGB cable giving you a crisper display at higher resolutions!
Features UL Approved Cabling
Filters included on both ends cutting down on noise
Maintains stronger signals using a shielded cabling run.
Comes in 15pin D-sub format with Male to Male conectors
