| BENQ MP610 DLP Multi Purpose PROJECTOR |
|
|
|
|
 |
 |
For the current BenQ Range Click here |
 |
 |
There are no limitations when using the MP610. It captures rich, true-to-life spectrums for the greatest visual satisfaction.
Enjoy perfect colours with the MP610's unique color matching technology. The new generation golden ration colour wheel balances true colour saturation and maximizes colour accuracy
Whisper quiet design
To ensure whisper quiet operation, BenQ adopts a special airflow design to cool down the system temperature, which creates a very effective sound baffle. The latest colour wheel mounting technique in its turn enhances stability. Because of this combination, the BenQ MP610 reduces audible noise to just 25 dB, ensuring an undisturbed meeting environment
 |
sRGB colors are always consistent among different display devices!
sRGB (Standard Red, Green and Blue) was developed to ensure standard, uniform reproduction of color coordinates regardless of the display device used. By meeting sRGB guidelines, color profiles of your projected images remain consistent with the original image. |
Unique Color Matching Technology
BenQ's Color Matching technology provides faithful image color reproduction by employing the new generation Golden Ratio Color Wheel. The Golden Ratio Color Wheel balances true color saturation and maximizes color accuracy. The Advanced Color Wheel coating technology enlarges the color gamut delivering even better color saturation; and the Optimized Gamma Adjustment ensures colors are projected honestly with the original input signal.
In the other words, there are no limitations when using the MP610. The MP610 captures rich, true-to-life spectrums for greater visual satisfaction and enjoyment. |
 |
 |
Our Say
As one of the best value projectors on the market, the new BenQ MP610 not only has a great modern appearance but a lamp life of up to 4000 hours. It's the perfect value option for those who would like to do a bit of everything with their projector. It offers an exceptional brightness rating of 2000 ANSI Lumens making it great for business presentations, home movies, retail advertising and even watching the footy on a Saturday afternoon.
The unit uses the latest DLP technology with a 5 segment colour wheel eliminating rainbow effects seen in its predecessors (PB6110, PB6210) and some older DLP models. |
This projector is relatively easy to carry around with a high quality soft carry case included. It comes with the required base mounting holes so can be ceiling mounted if required. A universal mount will cost approximately $169. |
|
Specifications
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Display Technology |
DLPT technology by Texas Instruments |
| Panel |
SVGA DDR DMDTM x 1 |
| Native Resolution |
SVGA (800 x 600) |
| Resolution Supported |
VGA(640 x 350) to SXGA(1280 x 1024) |
| Brightness |
2000 ANSI lumens |
| Contrast Ratio |
2000:1 (Full on/Full off) |
| Image Size |
31" to 300" |
| Throw Ratio |
55"@6.6 feet(55"@2m) |
| Zoom Ratio |
Manual Zoom, 1.15:1 |
| Displayable Colours |
Full 16.7 million color palette |
| Aspect Ratio |
4:3 Native, 16:9 Selectable |
| Light Source |
200W, 3000/4000 hours (Normal/Economic mode) |
| Operational Noise |
29/25 dB (Normal/Economic mode) |
| Horizontal Frequency |
31-82 kHz |
| Vertical Scan Rate |
48-85 Hz |
| Video Compatibility |
NTSC, PAL, SECAM |
| Dimensions (HxWxD) |
9.37x 3.70 x 11.14 inches (238 x 94 x 283 mm) |
| Net Weight |
6 lbs (2.72 kg) |
| Lens |
F=2.6 to 2.77, f=20.4 to 23.5 mm |
| Input Terminals |
PC |
Analog RGB: D-sub 15 pin x 1(shared) |
| |
A/V |
Component Video: D-sub 15 pin x 1(shared) |
| |
Composite Video: |
RCA x 1 |
| |
S-Video: |
Mini Din 4 pin x 1 |
| Audio |
PC audio: Stereo mini jack x 1(shared) |
| Video L/R audio: Stereo mini jack x 1(shared) |
|
|
| Output Terminals |
PC: Analog RGB: D-sub 15 pin x1 |
| Audio: 2 Watt speaker x1 |
|
|
| Control Terminals |
USB Connector : USB x 1, Type mini B |
| Serial Connector : RS232 8 pin MINI DIN |
| Power supply |
100 to 240 VAC, 50 to 60 Hz |
| Power Consumption (Max) |
Max 285W |
| OSD (On-Screen Display) languages |
English/ French/ German/ Italian/ Spanish/ Russian/ Traditional Chinese/ Simplified Chinese/ Japanese/ Korean/ Swedish/ Dutch/ Turkish/ Czech/ Portuguese / Thai/ Polish |
| Functions |
|
|
| Auto Phase Adjustment |
Mute |
Bitmap |
| Freeze |
Auto Source Detection |
Security Password |
| Blank |
HDTV Compatible |
Digital Keystone |
| Auto Off |
Macintosh® Compatible |
"Mode" Hot Key |
| Quick Cooling |
|
|
|
|
| Accessories Included |
|
|
| Quick Start Guide |
VGA Cable |
User's Manual |
| CD Manual |
USB cable |
Battery for R/C |
| Remote Control |
PWR Cord |
Soft Carry Case |
Supplied Accessories
|
Carry Bag |
Remote |
|
|
|
|
|
