Model: |
Product Name: |
|
XEED SX60 |
Product Class: |
|
Ultra Portable |
LCD Panel: |
Type: |
|
LCOS Reflective Display, TFT Active Matrix |
Size & Number: |
|
0.7" diagonal, 3 panels |
Aspect Ratio: |
|
4:3 |
Native Resolution: |
|
1400 x 1050 (SXGA+), 1470000 pixels |
Optics: |
Light Source: |
|
180W NSH Lamp |
Lens F Number & Focal Length: |
|
F1.85 - F2.5; f=21.7 - 35.8mm |
Zoom Magnification & Control: |
|
1.7x Motorised |
Focus Control: |
|
Motorised Auto Focus |
Lens Shift: |
|
9:1, fixed |
Image & Audio: |
Brightness: |
|
2500 lumens |
Uniformity : |
|
88% |
Contrast Ratio: |
|
1000:1 (full on/full off); 2000:1 (full on/full off) in Home Cinema Mode |
Projection Distance Coverage: |
|
1.2m - 9.0m (3.0m - 4.9m for 100" image) |
Screen size: |
|
40" - 300" (81 x 61cm - 610 x 457cm) |
Digital Zoom Magnification: |
|
1x - 12x |
Keystone Correction Range: |
|
 |
Vertical: ±20º (Auto/Manual) |
 |
Horizontal: ±20º (Manual) |
|
Digital RGB Compatibility: |
|
D-SXGA+/D-WXGA/D-SXGA/D-XGA/D-SVGA/D-VGA |
Analogue RGB Compatibility: |
|
UXGA (compressed)/SXGA+/WXGA/SXGA/XGA |
Video Colour Systems: |
|
PAL/PAM-M/PAL-N/NTSC/NSTC 4.43/SECAM |
HD/Component Scan Systems: |
|
1080i/1035i/720p/575p/575i/480p/480i |
Horizontal Video Resolution: |
|
550 TV lines |
Scanning Frequency: |
|
Horizontal: 15-100kHz; Vertical: 50-100Hz; Clock: 170MHz |
Display Modes: |
|
Standard, Presentation, Movie, Home Cinema, SRGB |
Image Enhancement Options: |
|
12-bit Digital Gamma Correction, 6-axis Colour Adjust |
Built-in Audio: |
|
1.0W RMS, Monaural |
Connectors: |
Digital RGB/Digital Video Input/ Analogue RGB Input 1: |
|
DVI-I 29-pin (HDCP Compatible) |
Analogue RGB Input 2: |
|
Mini D-Sub 15-pin |
Analogue RGB Output: |
|
Mini D-Sub 15 pin |
Component Video Input: |
|
Via 3 x RCA adaptor cable (supplied) |
S-Video Input: |
|
Mini-DIN 4 pin |
Composite Video Input: |
|
RCA x 1 |
Audio Input: |
|
3.5mm x2 stereo mini jack |
Mouse Control: |
|
USB Type B |
Service Port/Projector Control: |
|
Mini-DIN 8 pin |
Mechanisms: |
Front Elevation Mechanism: |
|
One-touch mechanical foot |
Maximum Elevation Angle: |
|
11.9º |
Ratings: |
Dimensions (W x H x D): |
|
266 x 114 x 336mm |
Weight: |
|
4.6kg |
Rated Supply Voltage: |
|
100V 240V AC, 50/60Hz |
Power Consumption: |
|
Normal Mode: 250W/ Quiet Mode: 225W/ Standby: 7W |
Noise Level: |
|
Normal Mode: 30dBA/ Quiet Mode: 27dBA |
Operating Environment: |
|
+5ºC to +35ºC |
Storage Environment: |
|
-30ºC to +60ºC |
Warranty: |
|
2 years (90 days for lamp) |
