                          |  INFOCUS IN3106 Widescreen Large Venue DLP MULTIPURPOSE PROJECTOR |




                                |
                                 |
                                  |
                                                                   |


                                  |


                                FOR CURRENT INFOCUS PROJECTORS CLICK HERE  |



                                  |








                                      Introduction
                                        The InFocus IN3106 widescreen digital   multimedia projector provides meeting room presenters with a WXGA-native   projector to ideally match widescreen laptops and HD presentation content. The   IN3106 features 3000 lumens with a 2000:1 contrast ratio and the true-to-life   colors of DLP® with BrilliantColor™ technology. This WXGA native (1280 x 800)   projector features DisplayLink content-over-USB for fast setup and the subtle   sophistication of LiteTouch™ control to stealthily blend into your meeting   space.


                                                                              |
                                        |




                                  Performance
                                  The IN3106 provides exceptional   performance and image reproduction due to InFocus advanced tuning of DLP® with   BrilliantColor™ technology. 3000 lumens offer the brightness to produce a   massive image, or shine through the most powerful overhead lights in your   meeting space while the 2000:1 contrast ratio provides outstanding image depth   and detail.



                                    Flexible Configuration
The widescreen   IN3106 digital projector will natively project HD 720P content and supports   Full-HD 1080P, along with any other content presented from your widescreen   computer. The IN3106 is easily ceiling-mounted, supports table-top and rear   projection, and is compact enough to move from room to room. 2 x 3 watt speakers   provide the audio muscle to amplify your brilliant presentation. When installed   the IN3106 features 30 degrees of vertical digital keystone to optimize the   image courtesy of remote control.

Connectivity
DisplayLink™ technology transmits audio & video content over   USB, offering the simplicity of zero display setup – just connect and present in   seconds. Combined with HDMI, VGA, Composite and a Wireless-Ready port for   LiteShow II Wireless the IN3106 will project from any video source or wireless   computer. Additionally the glossy backlit top panel of the IN3106 hides a   touch-sensitive LiteTouch™ control panel which takes the place of a traditional   button array to create a sleek profile for ceiling installations.

                                  Longevity
The IN3106 is protected under factory   warranty for 2 years from date of purchase. The projector lamp has a 6-month   warranty from defect or premature failure.


  |



                                  Specifications




                                           Display |


                                          | Native Aspect Ratio: |
                                          16x10 |


                                          | Supported Aspect Ratio: |
                                          16x10, 16:9, 4:3, 5:4 |


                                          | Brightness: (max ANSI lumens) |
                                          High Bright: 3000 Lumens
                                            Eco Mode: 2400 Lumens |


                                          | Contrast Ratio: |
                                          2000 : 1 Full On/Full Off |


                                          | Display Technology: |
                                          DLP by Texas Instruments: 0.65" WXGA DMD with Brilliant Color |


                                          | Data Compatibility: |
                                          VGA (640x480), SVGA (800x600), XGA (1024x768), SXGA (1280x1024), SXGA   (1400x1050), WXGA (1280x800), WXGA+ (1440x900), WSXGA+ (1680x1050) |


                                          | Video Compatibility: |
                                          Full NTSC, PAL, SECAM, 480i, 576i, 480p, 576p, 720p, 1080i,   1080p/60 |


                                          | Color Wheel (DLP Only): |
                                          5-segment |


                                          | Native Resolution: |
                                          WXGA |


                                          | Projector Placement: |
                                          Front Projection, Rear Projection, Ceiling Projection |


                                          | SMPTE Brightness: |
                                          Not Available |


                                          | Lamp Wattage: |
                                          High Bright: 230 Watts
                                            Eco Mode: Not Available |


                                          | Lamp Life: |
                                          High Bright: 3000 Hours
                                            Eco Mode: 4000 Hours |


                                          | Minimum Image Size: |
                                          3.25 ft (0.99 m) |


                                          | Maximum Image Size: |
                                          16.66 ft (5.08 m) |


                                          | Standard Lens Zoom: |
                                          1.1 : 1 |


                                          | Standard Lens Throw Ratio: |
                                          1.56 - 1.72 (Distance/Width) |


                                          | Standard Lens Image Offset Ratio: |
                                          115% |


                                          | Standard Lens Projection Distance: |
                                          5.11 - 36.15 ft (1.56 - 11.02 m) |


                                          | Digital Keystone Correction (Vertical): |
                                          +30°/-30° |


                                          | Digital Keystone Correction (Horizontal): |
                                          Not Available |


                                          | Lens Shift: |
                                          Not Available |


                                           Inputs and Outputs |


                                          | DVI: |
                                          Not Available |


                                          | M1: |
                                          Not Available |


                                          | HDMI: |
                                          Number of Inputs: 1
                                            HDMI v1.3, Deep Color |


                                          | BNC: |
                                          Not Available |


                                          | Component (RCA): |
                                          Number of Inputs: 1
                                            requires optional VGA to Component   adapter. |


                                          | VESA (HD15): |
                                          Number of Inputs: 2
                                            15-pin VGA |


                                          | S-Video: |
                                          Number of Inputs: 1
                                            4-pin mini-DIN |


                                          | Composite (RCA): |
                                          Number of Inputs: 1 |


                                          | Standard Definition TV: |
                                          Composite RCA, S-Video, HDMI |


                                          | Enhanced Definition TV: |
                                          VGA, HDMI |


                                          | High Definition TV: |
                                          VGA, HDMI |


                                          | Computer: |
                                          VGA, USB (DisplayLink), HDMI |


                                          | HDCP Support: |
                                          Yes |


                                          | Stereo RCA Jacks Inputs: |
                                          Yes |


                                          | Stereo 3.5 mm Mini-jack Inputs: |
                                          Yes |


                                          | 12v trigger for motorized screens (3.5 mm mini-jack): |
                                          No |


                                          | Projector Control: |
                                          Projector Keypad, Remote, USB, RS-232 |


                                          | Speakers: |
                                          (2) 3 Watt stereo speakers |


                                          | Monitor Output: |
                                          Yes |


                                          | Audio Output: |
                                          3.5mm Stereo Mini-jack |


                                           Compatibility |


                                          | Data Compatibility: |
                                          VGA (640x480), SVGA (800x600), XGA (1024x768), SXGA (1280x1024), SXGA   (1400x1050), WXGA (1280x800), WXGA+ (1440x900), WSXGA+ (1680x1050) |


                                          | H-Sync Range: |
                                          15.75 - 100kHz |


                                          | V-Sync Range: |
                                          50 - 85Hz |


                                          | Video Compatibility: |
                                          Full NTSC, PAL, SECAM, 480i, 576i, 480p, 576p, 720p, 1080i,   1080p/60 |


                                           General |


                                          | Audible Noise: |
                                          33 dB, 28dB(eco)  |


                                          | Actual Dimensions: |
                                          Height: 3.7 in (9.4 cm)
                                              Length: 9.8 in   (24.89 cm)
                                              Width: 12.4 in (31.5 cm)
                                           |


                                          | Actual Weight: |
                                          7 lbs (3.18 kg) |


                                          | Shipping Dimensions: |
                                          Height: 13.1 in (33.27 cm)
                                              Length: 8.8   in (22.35 cm)
                                              Width: 18.8 in (47.75 cm)
                                           |


                                          | Shipping Weight: |
                                          14.3 lbs (6.49 kg) |


                                          | Projector Warranty: |
                                          2 years - Filter Free Design and 24 hour operation compatible |


                                          | Lamp Warranty: |
                                          6 months |


                                          | Accessories Warranty: |
                                          90 days |


                                          Operating temperature:
                                            (at sea level) |
                                          41 - 95° F (5 - 35° C) |


                                          | Maximum Altitude Supported: |
                                          10000 ft (3048 m) |


                                          | Typical Power Consumption: |
                                          228 Watts |


                                          | Maximum Power Consumption: |
                                          288 Watts |


                                          | Power Supply: |
                                          100 - 240 Volts at 50 - 60 Hz |


                                          | Menu Languages: |
                                          English, French, German, Italian, Korean, Norwegian, Portuguese, Russian,   Simplified Chinese, Spanish, Traditional Chinese, Swedish, Dutch, Polish,   Turkish, Danish, Finnish |


                                          | Approvals: |
                                          UL and c-UL (US/Canada), FCC (US/Canada), CE (CE member countries), GOST   (Russia), TUV GS (Germany), CCC (China), IRAM (Argentina), NOM (Mexico), C-Tick   (Australia), MIC & eK (South Korea), PSB (Singapore), RoHS |


                                       |





                                            Supplied Accessories

  |


                                            Remote  |


                                             |



                                      Optional Accessories  |



                                                                                |

                                      |
                                         |
                                       Extended Warranty
                                           |





    Program Coverage:
    - LCD & Plasma pixels are covered only as per original manufacturer's pixel terms & conditions
    - Does not cover Cords, Power Adapter
    - Does not cover consumable items such as projector globes  |


                                      | + 3 Year On-Site Extended Warranty (up to 5 years total)  |
                                      $249 |


                                      | + 2 Year On-Site Extended Warranty  |
                                      $179 |


                                      | + 1 Year On-Site Extended Warranty  |
                                      $140 |









                                                                                |

                                      |
                                         |

                                       Viewsonic  WPG-350  Wireless Presentation Gateway   |


                                          Pick Up Avail.


        |


                                      - Upgrade any Projector To Wireless
                                        - Fully compatible with both Windows and Mac® OS
- Supports resolutions up to 1024x768 and full-motion
                                          video up to 1080p
- Presentation remote for total conference control
- Equipped with VGA pass-through for an extra display |



                                                                                |

                                      |
                                         |

                                         Premium VGA Monitor Cable (15HDM/15HDM)    |







                                          Aus Wide Delivery: $15

                                       |



                                         Heavily shielded coaxial RGB cable giving you a crisper display at higher resolutions!




                                            | .  |
                                            Features UL Approved Cabling  |


                                            | .  |
                                            Filters included on both ends cutting down on noise  |


                                            | .  |
                                            Maintains stronger signals using a shielded cabling run.  |


                                            | .  |
                                            Comes in 15pin D-sub format with Male to Male conectors  |


                                            |   |
                                              |



                                         |




                                      | Buy your new in3106 projector now, Contact Us today! |

                                    |

                                                          |






                      |
