Introducing a line of digital projectors designed for the cinematic connoisseur: the Mitsubishi HC1100U Projector.
High contrast of 3000:1
Adoption of the new DarkChip2™ and optical engine mounted with high-detail all-glass
lens, realizing native contrast of 3000:1.
Newly developed color wheel to reproduce natural tones (RGB RGB)
Adopts standard light D65 color temperature
The key to reproduce visual sources in more realistic color tones.
Mounted with a quadruple speed color wheel to reproduce the
color temperature considered to comprise standard light - D65
(6,500K).
Fine-detail gradation reproduction, approaching the high-end realm
Equipped with full 10-bit panel driver (DDP3020)
Formatter board mounted with integrated full
10-bit processing I/P conversion/scaler
and 12-bit floating point digital gamma correction equivalent to 20-bits.* Generates
some 4 times the gradation of conventional 8-bit models, portraying subtle dark area
gradation in smooth and flowing images.
High-speed LVDS (low-voltage differential signal) drive
Equipped with high-speed memory (RLDRAM) to raise data transmission efficiency, in tandem with high-speed
LVDS drive. The resulting high-caliber gradation expression challenges the high-end model range.
The 10-bit I/P conversion circuit zaps pesky jaggies for good
Mounted with full 10-bit processing I/P conversion circuits that forge dramatic |
 |
| improvements in noise. Impressive cuts in diagonal jaggies, ensuring smooth and striking image duplication. |
DarkChip2TM realizing high resolution of 1280×720 dots
Adoption of 1280×720 dot high-resolution DMD chip (wide panel). The mirror inclination
angle of ±12 degrees effectively cuts
black shade diffused light. What's more,
the switch to dark metal in the mirror rear
structure blocks diffuse reflection and
stray light, opening the door to rich and
fine gradation expression.
| Selective use of high brightness and high definition modes, tailored to the images being screened |
Standard mode (1000lm)
Enhances viewing even in comparatively bright
rooms - dynamic images for sporting events and
other TV entertainment. |
Low mode (750lm)
Reproduction of enh
anced black gradation
app-roaching the high-end model realm, for dynamic
movie viewing that stresses the value of dark, black |
User gamma correction
Complementing the three modes of Sports, Video
and Cinema, for movie viewing this projector
zeroes in on the demands for "higher black level reproduction," "brighter medium contrast" and "toned down highlights" unachievable with conventional
brightness functions. The key to success is independent
operation of black, medium, and white gradation,
ensuring subtle picture change and adjustment.
|
