Epson EMP-TW700 Projector at Just Projectors!

Epson EMP-TW700 TFT High Definition Home Theatre Projector

DISCONTINUED

FOR CURRENT EPSON PROJECTORS CLICK HERE

(AKA) Epson PowerLite Home Cinema 720
High Definition - Home Cinema Projector

EMPTW700 Reviews:
	"Panasonic have also released a new home theatre projector with similar specifications to the Epson, however after viewing both we have chosen the Epson as our recommended unit. This is due to the higher contrast ratio the Epson offers, the higher optical zoom, and the fact that Epson actually manufacture the LCD panel for Panasonic resulting in both projectors having the same image base. While the Panasonic is capable of a slightly higher brightness level, it does loose a fair bit a colour accuracy and contrast when doing so."

	A step up from its predecessor, the TW700 is shipped with a tweaked version of the company's D5 3LCD engine and an improved Cinema Filter. The former, when paired with an automated dual-iris optics, enables the projector to deliver a two-fold leap in contrast performance of up to 10,000:1. This is adequately matched by an above-average 1,600 ANSI lumen brightness which first debuted in its predecessor, handy for countering ambient lighting in less ideal environments.

Our Say
Epson has once again confirmed its position as the leader in LCD projectors with this great new high definition home theatre unit. With such a large quantity of home theatre projectors available Epson has done their research and come up with a bright Hi-Def projector with an exceptional contrast ratio or 10000:1, yes that ten thousand to one. If your after a home theatre projector under $2500 this is it.
Click here for our EMP-TW700 Review

The new EMP-TW700 by Epson
Welcome to a world where everything from the latest generation video games right through to breathtaking high definition movies are given true widescreen treatment. Introducing the powerful Epson EMP-TW700 Home Cinema Projector, featuring a massive 10,000:1 contrast ratio and 10-bit colour processing for reproducing 1.07 billion colours!

HDMI-Equipped
An increasing number of DVD movie publishers are releasing high definition versions of their movies, and the need for high definition video display capabilities are making their way further up the list of "must haves". With a built-in High Definition Multimedia Interface (HDMI), the Epson EMP-TW700 accepts all-digital uncompressed signal direct from the source ensuring there's no longer any need to wait to get the movie experience of a lifetime.

10-bit colour
As a world leader in the development and manufacture of projector LCDs, Epson is constantly at the forefront of delivering projectors that stand out from the crowd - and the Epson EMP-TW700 is one more example of this. With 10-bit colour processing capabilities, the EMP-TW700 is capable of reproducing a massive 1.07 billion colours for incredibly rich expression and smooth gradation.

The widescreen experience
When it comes to a truly big screen experience, Epson home cinema projectors deliver virtually incomparable performance. Forget about other display technologies if you're really looking for image sizes that are bigger than life. For big screens of 2 metres or more the EMP-TW700 is perfect, adding enormously to every widescreen television show, DVD or video game. All this from a unit measuring only 406mm x 353mm x 143mm that can be installed on the ceiling or on a small side table.

Advanced 3LCD technology
At the heart of the EMP-TW700 is Epson's world-leading 3LCD technology. This projection system uses three individual LCD panels to give form to images with silky smooth movement and fresh, natural colours.

Bright, vibrant colours and unequalled image quality is characteristic of 3LCD technology, with the EMP-TW700 delivering outstanding results in any presentation environment - regardless of whether the lights are on or off!

Due to 3LCD's incredibly efficient use of light, projectors based on this technology are able to achieve quiet operating levels, exceptional clarity and flicker-free presentations.

Epson Cinema Filter
Epson home cinema projectors are well-known for their use of Cinema Filter technology - a technology built in to the projector's optics system and providing a crucial role in the ability to achieve wider colour spaces and colour purity. With the Epson EMP-TW700, things have taken a step forward once again.

In its adjustment of the three primary colours (Red, Green and Blue), the new generation Epson Cinema Filter achieves even finer adjustment and balance precision than with earlier models. The result - the Epson

EMP-TW700 projects images with greater depth and accuracy of colours, making it the perfect home cinema projector.

High contrast ratio
Brightness and colour are only two of the vital characteristics of a projector; and the difference between a good and a great projector. In order to achieve maximum image display quality, a high contrast ratio is absolutely essential. With the Epson EMP-TW700 that quality is

delivered by means of a massive 10,000 to 1 contrast ratio.

One of the technological advances that make such a high contrast ratio possible is the Auto Iris Function; a powerful function that controls lamp brightness levels 60 times every second. When the projector is displaying a light scene the iris is opened, allowing more light to pass through to LCD panels resulting in a brighter image. For dark scenes, the iris opening is reduced, delivering richer blacks than are possible under less advanced systems.

Flexible placement
With exceptional horizontal and vertical lens shift capabilities, the Epson EMP-TW700 can be positioned well off-centre - up to two screen widths laterally and three screens vertically - without distorting the screen shape or in any way compromising the image quality. It's just another example of how Epson home cinema projectors have been designed specifically for the home cinema experience.

Light-efficient lamp technology - E-TORL
One of the crucial factors in the EMP-TW700's capability of providing up to 1600 ANSI lumens in dynamic mode is the incredibly efficient E-TORL (Epson Twin Optimised Reflection Lamp) technology. Designed to minimise light leakage - a primary cause of lamp inefficiency - and minimise light diffraction, E-TORL lamps are so small and efficient as to be well ahead of their time.

Specifications

PRODUCT TYPE	Home Theatre Projectors
PRODUCT NAME	EMP-TW700
PRODUCT CODE	V11H244053
PROJECTION SYSTEM	D5 Liquid Crystal Display
PROJECTION METHOD	Front / Rear / Ceiling Mount
SPECIFICATION OF MAIN PARTS
LCD	Size 0.7 inches wide MLA
Driving method	Poly-Silicon TFT Active Matrix
Pixel number	1280 x 720 pixels
Native resolution	720P
Aspect ratio	16:9
Pixel arrangement	Stripe
Refresh Rate	50Hz or 60Hz (based on input signal)
PROJECTION LENS	Type manual: zoom / focus
F-number	2.0 - 3.17
Focus length	22.5 - 47.2mm
Zoom ratio	1.0:2.1
LAMP Type	170 W UHE E-TORL Lamp
LAMP Life	1700hrs or 3000hrs (Theatre Black 1 and 2)
SCREEN SIZE (PROJECTED DISTANCE)	30 to 300 inch (0.93 to 9.61m) (Wide) 30 to 300 inch (2.00 to 20.35m) (Tele)
LENS SHIFT RANGE	Vertical: 102.3% max. (upward & downwards) Horizontal: 50% max. (Left and Right)
BRIGHTNESS	High Brightness Mode	1600 ANSI lumens
Colour Mode	( Dynamic, Zoom: Wide, Lens shift: Full, Auto iris: On )
CONTRAST	10000:1 ( Colour Mode: Dynamic, Zoom: Wide, Lens shift: Full, Auto iris: On )
BRIGHTNESS UNIFORMITY	87.9%
COLOUR REPRODUCTIVITY	10bit colour processing
COLOUR SPACE	134% of sRGB
EFFECTIVE SCANNING FREQUENCY RANGE
PIXEL CLOCK	13.5MHz to 110MHz
HORIZONTAL	15 to 92KHz
VERTICAL	50 to 85Hz
ADJUSTMENT FUNCTION
PROJECTOR / REMOTE CONTROL	Keystone (Vertical) / Brightness / Contrast / Tint / Saturation / Input signal etc.
TILT ANGLE	0 to 2.1 degrees
KEYSTONE CORRECTION	Vertical: -15 to +15 degrees ( Zoom: Tele )
EPSON CINEMA FILTER	Controlled automatically with color mode (ON: Theatre Black 1 and 2 / Natural / s-RGB, OFF: Living Room / Dynamic)
AUTO IRIS	Controlled automatically adjusting to video source. (Available at all colour modes; user selectable ON/OFF on OSD)
EPSON SUPER WHITE	Controlled automatically adjusting to video source (Available at Natural/Theatre/Theatre Black 1 and 2; user selectable ON/OFF on OSD)
ANALOGUE RGB I/O
DISPLAY PERFORMANCE Native	750P
Resize	1280 x 1024 / 1280 x 768 / 1360 x 768 / 1024 x 768 / 800 x 600 / 640 x 480 / 525i / 625i / 525p / 625p / 1125i
INPUT SIGNAL Signal type	Separate signal
Video signal Analog	(0.7V p-p,75 ohm/ Mac0.714Vp-p, 75ohm)
Sync. signal Separate	(positive & negative, bi-polarity 2-5Vpp) / Composite (positive & negative, bi-polarity 2-5Vpp) / Sync-on-green (negative, 0.3Vpp)
INPUT TERMINAL Video	Mini D-sub 15 pin x 1 Blue molding
VIDEO I/O
COMPONENT INPUT
INPUT SIGNALVideo standard	525i / 625i / 525P / 625P / 750P / 1125i
Video signal Component Video	(Analog Y level 0.7V 75 ohm / Cr Cb level +/-0.35V 75 ohm / sync. negative 0.3V or 3-state +/-0.3V on Y)
INPUT TERMINAL	RCA x 3 (Red / Green / Blue) x 2, D4 video
COMPOSITE / S-VIDEO
INPUT SIGNAL	Video standard NTSC / NTSC4.43 / PAL / M-PAL / N-PAL / PAL60 / SECAM
Video signal Composite Video	(1.0Vpp / Sync.negative, 75 ohm) / S-Video (Luminous 0.714Vpp, Chrominous 0.286Vpp, 75 ohm)
INPUT TERMINALS-Video Mini DIN Video RCA (Yellow) x 1
HDMI
DISPLAY PERFORMANCE Native	750P
INPUT SIGNAL Video Standard	525i / 625i / 525P / 625P / 750P / 1125i
Video Signal	TMDS ( Signal for HDMI)
INPUT TERMINAL	Video HDMI (High Definition Multimedia Interface) x 1
CONTROL I/O
SERIAL I/O	I/O terminal D-sub 9 pin x 1 I/O signal RS-232c
LOCK FUNCTION	Operation Lock & child-lock
OPERATING TEMPERATURE	5°C to 35 °C <41°F to 95 °F>
DIRECT POWER ON	Yes
COOL-DOWN PERIOD	Approx 30 seconds
START-UP PERIOD	To lamp on: Approx 10 seconds
POWER SUPPLY VOLTAGE	100-240 VAC ±10%, 50/60Hz
POWER CONSUMPTION 240W (Lamp High),	200W (Lamp Low)
DIMENSIONS
EXCLUDE FEET	406mm(W) x 310mm(D) x 124mm(H)
MAXIMUM DIMENSION	406mm(W) x 353mm(D) x 143mm(H)
WEIGHT	Approx. 5.4kg
FAN NOISE
HIGH BRIGHTNESS MODE	33dB (Colour mode: Dynamic)
WHISPER MODE	26dB (Theatre Black 1 and 2)
ACCESSORIES
POWER CORD 3m REMOTE CONTROL Stick type (backlight) BATTERY Alkaline, size AA x2 USER'S MANUAL Included LENS CAP Included
WARRANTY
2 years 6 Months on Lamp or 750 hours
