Optoma EH416 DLP Full HD Widescreen Projector


EH416




Home Theatre
Home Theatre

Business


Your Price: $1749

Flat Rate Freight!
$22 Insured Australia Wide.
Pick up Available


Quick Facts:
Optoma EH416 Throw Distance Chart (Examples for common Sizes)
Image Size Installation Distance
(Approx. To Lens)
92" (16:9) 2030x1140mm From 2.6m to 4.6m
100" (16:9) 2130x1200mm From 3.1m to 5.0m
110" (16:9) 2435x1370mm From 3.4m to 5.5m
120" (16:9) 2580x1450mm From 3.7m to 6.0m
SPECIFICATIONS
Native Resolution: WUXGA 1920 x 1080 16:9
Brightness: 4200 ANSI Lumens
Maximum Contrast: 20,000:1
Weight: 2.99kg
Fan Noise: 32db (eco)
Warranty: 3 Years (+1 Year $125)
Lamp Warranty: 12months/1000hrs
Lamp Life Up To: 7
,000hrs
FEATURES
- 2x HDMI Connection
- Powerful 10W Speaker
- 1.6x Zoom
- 17% Vertical Lens Shift

- 3D Capable(3D glasses required)
- Optional wireless

EH416 Full HD 1080p, compact and powerful

  • Bright 1080p projector – 4200 ANSI Lumens
  • Installation flexibility – Vertical lens shift and 1.6x zoom
  • Ultimate Control - Full support for Crestron, Extron, AMX, PJ-Link and Telnet LAN commands
  • Easy connectivity - HDMI, MHL, VGA, 10W speaker

Project high resolution visuals regardless of the ambient light level using the bright full HD 1080p EH416. Designed for businesses and professional installation environments this compact and powerful projector can be installed or taken on the move. Perfect for small edge blending and stacking projects.

Easy to connect to with multiple inputs including two HDMI, MHL, VGA and a built in 10W speaker. You can even present wirelessly using the HDCast Pro (sold separately) or use the USB Power to connect and power HDMI dongles such as the Google Chromecast.

For more complex installations, this projector is equipped with a large 1.6x zoom range, vertical lens shift and networking features for remote monitoring and control.

Large zoom range

A large zoom range enables multiple placement possibilities at a variety of distances from the projection screen. An advantage to this is that expensive interchangeable lens projectors can be substituted with a more cost effective solution whilst still retaining a diverse choice of positioning options.

Vertical lens shift

Simplify installation with vertical lens shift, which provides a wider range of projector placement possibilities. This makes it easier to position the projector in your room and enables a wider range of screen size options.

High contrast

Add more depth to your image with a high contrast projector; with brighter whites and ultra-rich blacks, images come alive and text appears crisp and clear - ideal for business and education applications.

S2015

Full 3D

Optoma projectors can display true 3D content from almost any 3D source, including 3D Blu-ray players, 3D broadcasting and the latest generation games consoles. Support for 144Hz rapid refresh rate provides ultra-smooth flicker free images.

Integrated speaker

A powerful built-in speaker provides exceptional sound quality that is easy to set up without the need for costly external speakers

Eco+

Eco+ technology brings together high contrast, improved lamp life and energy saving features that are easy to use while reducing power consumption.

Energy saving

Using the specially designed lamp modes, you can reduce the power consumption by up to 70%. Each mode also has a positive effect on the lamp life, while lowering the total cost of ownership and reducing maintenance.

Quick resume

This feature allows the projector to be instantly powered on again, if it is accidentally switched off.

Auto power off

There may be instances when the projector is left running when not in use. To help save energy, the "Auto Power Off" feature automatically turns off the projector after a set period of time if it is not being used

USB power

Use the USB-Power to power an HDMI dongle, such as Google Chromecast.

Eco AV mute

Stay in control of your presentation with Eco AV mute. Direct your audience's attention away from the screen by blanking the image when no longer needed. This also reduces the power consumption by up to 70%, further prolonging the life of your lamp.

S316 AV Mute

Long lamp life

Reduce the number of lamp changes with lamp life of up to 8,000 hours² using the Education Cycle.

Brilliant Colour

Colour guarantee

Enjoy dazzling colours for years to come; guaranteed by Optoma for five years’ consistent performance.

Amazing Colour

Watch your movies, TV shows and play games with stunning colours in any environment. Optoma projectors provides you with reliable performance suitable for any content and environment. Our home projectors are capable of reproducing the Rec.709 colour gamut, the international HDTV standard to guarantee accurate reproduction of cinematic colour exactly as the director intended. Or more saturated colours for a punchy looking image, great for gaming and animated movies.

Wireless

Stream Full 1080p 3D content to your projector wirelessly; eliminating the hassle and extra cost of installing long cables, the WHD200 (sold separately) allows you to connect a Blu-ray™ player, set-top box, gaming console or AV receiver instantly.

MHL

Turn your projector into a smart display by connecting your smartphone or tablet with a single cable using MHL; now you can view presentations and documents, stream videos and share photos on the big screen. You can even use MHL to connect and power the HDCast Pro (sold separately).

EH416
Projector Screen Bundle





Specifications

EH416 Specification

Display Technology Single 0.65” DarkChip 3 1080p DLP® Technology by Texas Instruments
Native Resolution 1080p 1920 x 1080
Brightness1 (Bright Mode) 4200 ANSI Lumens
Contrast 20,000:1
Lamp Life2 Eco+/Dynamic/Eco/Bright 7000/6000/5000/3000 (hrs)
Throw Ratio 3 1.4 - 2.24:1
Zoom Type 1.6x Manual
Lens Shift +17% Vertical
I/O Connectors 2 x HDMI (1.4a 3D support) + MHL v2.2, VGA (YPbPr/RGB), Composite, 2 x Audio in 3.5mm, VGA out, Audio out 3.5mm, RS232, RJ45, USB-A Power, USB mouse/service
Speaker 10
Keystone Correction ± 40° Vertical
Weight (kg) 2.99
Dimensions (W x D x H) (mm) 314 x 224 x 114
Aspect Ratio 16:9 Native, 4:3 Compatible
Offset 99% ~ 116%
Projection Screen Size 0.67 – 7.7m (26.21” - 303.3”) Diagonal 16:9
Projection Distance 1.3 - 9.4m
Projection Lens F/2.5~3.26; f=20.91~32.62mm
Uniformity 75%
Computer Compatibility UXGA, SXGA, WXGA, HD, XGA, SVGA, VGA, Mac
Video Compatibility PAL SECAM 576i/p, NTSC 480i/p, HD 720p/1080i/1080p
3D Support Full 3D - The 3D features of Optoma projectors can only be used with compatible 3D content. Typical applications include use with 3D educational or 3D design and modelling systems. 3D TV broadcast systems, (SKY in the UK), Blu-ray 3D™ and 3D games from the Sony® PS3 or Microsoft® Xbox 360 are now supported as part of the HDMI v1.4a specification.
3D Compatibility Side-by-Side:1080i50 / 60, 720p50 / 60
Frame-pack: 1080p24, 720p50 / 60
Over-Under: 1080p24, 720p50 / 60
Horizontal Scan Rate 15 - 91kHz
Vertical Scan Rate 24 - 120Hz
Displayable Colours 1.07 Billion
Noise Level (Eco mode) 32dB
Power Supply 100-240V, 50-60Hz
Power Consumption 309W Bright mode / 249W Eco mode (<0.5W Standby)
Lamp Type 260W
Security Kensington lock, password protection
On Screen Display 19 Languages: English, German, French, Italian, Spanish, Portuguese, Polish, Dutch, Russian, Finnish, Swedish,Greek, Norwegian/Danish, Hungarian, Czech, Arabic, Turkish, Farsi, Romanian
Standard Accessories AC power cord, remote control, 2x AAA batteries, quick start card, CD user manual
Supplied Accessories
Remote
EH416 Remote
Rear Panel

EH416 Rear Connections



Optional Accessories
